36
ENGLISH
Indications Selectable settings, [reference page]
Disc Setup 2
*3
Speaker Level*
1
You can adjust the output level of each speaker monitoring
the test tone.
Press and hold ENT to activate (or cancel) the test tone.
• Front Lch/Center ch/Front Rch/Rear Rch/
Subwoofer*
2
/Rear Lch: adjust the output level of each
speaker in the range of –10dB –+10dB. [Initial]; 00dB
Speaker Distance
*4
You can adjust the speaker output timing separately for each
speaker according to the distance from the speakers to the
listening position.
• Front Lch/Center ch/Front Rch/Rear Rch/Rear Lch:
adjust the speaker distance in the range of 15 cm to 600 cm
in 15-cm step.
[Initial]; 120 cm (for center speaker), 150 cm (for the other
speakers)
*
1
When activating the test tone, white noise comes out and cycles between the speakers activated on
“Speaker Size” [35] for about 2 seconds each. Press 5 / ∞ repeatedly while the test tone comes out
from the target speaker to adjust the settings (the test tone continues to come out from the target
speaker during the adjustment).
*
2
The setting is effective only when a multi-channel source is played back and Disc Surround is on, or
when Dolby PLII Movie/Music is in effect. Adjust the level on “Subwoofer” [39] for other cases.
*
3
Selectable only when DISC is the source.
*
4
Unselectable when all the speakers other than front ones are deactivated on “Speaker Size” [35].
Adjusts the speaker level
Selects the speaker to adjust
Selects the speaker to adjust
Adjusts the speaker distance
Selects the speaker to adjust
Selects the speaker to adjust
AVX2[U]EN.indb 36AVX2[U]EN.indb 36 06.2.8 2:05:35 PM06.2.8 2:05:35 PM
