JVC KD-AVX2J - Page 32

1-32 (No.MA254)
4.10 Monitor adjustment
* When adjusting, switch on the main unit and insert a test disc (VT-501). And play the test disc and pause it.
(1) Set the service mode 4.
(2) Exchanging it operate a menu of a service mode with the [UP] button and [DOWN] button.
(3) Change data with the [B.SKIP]/[F.SKIP] buttons.
(4) Write data with a [OK] button.
R/W CHROMA 1
Indication Minimum value Maximum value Initial value Reference register value
COLOR NTSC
COLOR PAL
TINT NTSC
TINT PAL
PHASE NTSC
PHASE PAL
CONT-VIDEO
CONT-RGB1
CONT-RGB2
GAMMA1
GAMMA2
RGB AMPLITUDE
BRIGHT
SUB-BRIGHT R
SUB-BRIGHT B
COM AMPLITUDE
COM DC
DAC OUT NTSC
DAC OUT PAL
H POSITION
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
1F
FF
FF
FF
FF
3F
3F
FF
FF
FF
FF
FF
FF
FF
FF
FF
FF
FF
FF
FF
1F
03
5B
5C
9F
98
20
20
78
00
00
B9
80
7B
76
79
7D
76
35
80
79
1D
03
66
67
A2
9B
20
20
6C
00
00
BC
00
7E
75
7A
7D
73
35
7A
74
1D
Fix
Adjust
Adjust
Adjust
Adjust
Fix
Fix
Adjust
Fix
Fix
Adjust
Fix
Adjust
Adjust
Adjust
Adjust
Adjust
Adjust
Adjust
Adjust
Fix
R/W CHROMA 3
AGC SW
GAM TEST
NTSC/PAL
00
00
AUTO
Fix
Fix
DVD picture change (NTSC or PAL, and or AUTO)
