JVC KD-AVX2J - Page 39

Contents
Block diagram
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-8 to 10
CD-ROM No.SML200604
SCHEMATIC DIAGRAMS
DVD/CD PLAYER
No.MA254SCH
2006/4
KD-AVX2J,KD-AVX2E,KD-AVX2EU
KD-AVX2EE,KD-AVX2U,KD-AVX2UN
KD-AVX2A
COPYRIGHT 2006 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
