1-26 (No.MA158)
A B
Frror code (1 byte)
First byte [01] Eject error
[09] Loading error
Detailed error codes (2 bytes) Displayed with loading/ejection errors only.
First byte
Second byte
Higher 4 bits
Lower 4 bits
[1] Time out
[2] Switch status error
[3] Swinging error
bit7
bit6,5
bit4
bit3
bit2
bit1
bit0
C D
Route No. (Process of error occurrence)
Refer to charts 1.1 and 1.2.
Error type
Disc type (0: 12 cm. 1: 8 cm)
Fixed at 0
SW1 status
SW2 status
SW3 status
SW4 status
REST SW status
(Example) When a switch status error occurs during loading route 3 and
the switch status is L/L/H/H/H (00111B = 07H), the error code
and detailed error code become: [09 3207].
Route No. (EJECT route No.)
-
1(2)
1(2)
2(2)
2(2)
2(2)
2(2)
3(1)
3(1)
Chart 1.1 12cm Disc switch status transition
SW1/2/3/4
1,1,1,1
0,1,1,1
0,0,1,1
0,0,0,1
0,0,1,1
0,1,1,1
1,1,1,1
1,1,1,0
1,1,1,0
[Rest SW]
[0]
[0]
[0]
[0]
[0]
[0]
[0]
[0]
[1]
Loading
No Disc
Disc insert
detection
Load completion
Eject
No Disc
Eject
completion
Eject start
Reload
Disc push in
Reload start
Load completion
Route No. (EJECT route No.)
-
1(2)
1(2)
2(2)
2(2)
3(1)
3(1)
Chart 1.2 8cm Disc switch status transition
SW1/2/3/4
1,1,1,1
0,1,1,1
0,0,1,1
0,1,1,1
1,1,1,1
1,1,1,0
1,1,1,0
[Rest SW]
[0]
[0]
[0]
[0]
[0]
[0]
[1]
Loading
No Disc
Disc insert
detection
Load completion
Eject
No Disc
Eject
completion
Eject start
Reload
Disc push in
Reload start
Load completion
Transition in the center loading (Similar to 12cm in the side loading)
Press the [SEL] key
"CD ERROR" is
indicated on the LCD.
Read loading and ejection error history
: The error history saved in the system control
is read and displayed.
TOT-xxxx : Total error count.
Total error count
(A figure between 0 and 9999 is
displayed. 10000 or more is also
displayed as 9999.)
Enyyzzzz : Latest three error codes.
Detailed error code
Error code
Counter
0nyyzzzz : First five error codes
Detailed error code
Error code
Counter
Exchanging it operate each indication with the
[DISC UP] button and [DISC DOWN] button.
