3-10

C784 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C801 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C841 QEKJ1HM-105Z E CAPACITOR 1uF 50V M

C881 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

C891 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C901 QEZ0675-338 E CAPACITOR 3300uF

C902 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C903 QEKJ1CM-476Z E CAPACITOR 47uF 16V M

C904 QEKJ1AM-107Z E CAPACITOR 100uF 10V M

C905 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

C906 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

C907 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

C908 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C909 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C910 QEKJ1CM-107Z E CAPACITOR 100uF 16V M

C913 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C914 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

C915 QEKJ1CM-476Z E CAPACITOR 47uF 16V M

C916 QEKJ1CM-106Z E CAPACITOR 10uF 16V M

C951 QEKJ1AM-107Z E CAPACITOR 100uF 10V M

C952 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C953 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C954 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C993 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C994 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C995 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C996 NCB31HK-103X C CAPACITOR 0.01uF 50V K

R1 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

R2 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

R4 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R5 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R6 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R7 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R8 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R9 NRSA63J-332X MG RESISTOR 3.3k

Ω

1/16W J

R10 NRS181J-100X MG RESISTOR 10

Ω

1/8W J

R12 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

R31 NRSA02J-100X MG RESISTOR 10

Ω

1/10W J

R32 NRSA63J-622X MG RESISTOR 6.2k

Ω

1/16W J

R33 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

R38 NRSA63J-101X MG RESISTOR 100

Ω

1/16W J

R39 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

R40 NRSA63J-393X MG RESISTOR 39k

Ω

1/16W J

R41 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

R42 NRSA02J-100X MG RESISTOR 10

Ω

1/10W J

R43 NRSA63J-471X MG RESISTOR 470

Ω

1/16W J

R44 NRSA63J-221X MG RESISTOR 220

Ω

1/16W J

R51 NRSA63J-471X MG RESISTOR 470

Ω

1/16W J

R52 NRSA63J-153X MG RESISTOR 15k

Ω

1/16W J

R53 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

R54 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

R55 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R56 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R57 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R58 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R59 NRSA63J-273X MG RESISTOR 27k

Ω

1/16W J

R71 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R72 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R73 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R74 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

R75 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R76 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R77 NRSA02J-100X MG RESISTOR 10

Ω

1/10W J

R81 NRSA63J-822X MG RESISTOR 8.2k

Ω

1/16W J

R82 NRSA63J-183X MG RESISTOR 18k

Ω

1/16W J

R91 NRSA63J-822X MG RESISTOR 8.2k

Ω

1/16W J

R92 NRSA63J-183X MG RESISTOR 18k

Ω

1/16W J

R161 NRSA63J-224X MG RESISTOR 220k

Ω

1/16W J

R162 NRSA63J-224X MG RESISTOR 220k

Ω

1/16W J

R164 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R165 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R166 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R167 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R168 NRS181J-100X MG RESISTOR 10

Ω

1/8W J

R169 NRSA63J-333X MG RESISTOR 33k

Ω

1/16W J

R170 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J



Symbol

No.

Part No. Part Name Description Local

R171 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R172 NRSA63J-273X MG RESISTOR 27k

Ω

1/16W J

R173 NRSA63J-273X MG RESISTOR 27k

Ω

1/16W J

R174 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R175 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R176 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R177 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R178 NRSA63J-273X MG RESISTOR 27k

Ω

1/16W J

R179 NRSA63J-273X MG RESISTOR 27k

Ω

1/16W J

R241 NRSA63J-333X MG RESISTOR 33k

Ω

1/16W J

R242 NRSA63J-102X MG RESISTOR 1k

Ω

1/16W J

R243 NRSA63J-470X MG RESISTOR 47

Ω

1/16W J

R244 NRSA63J-123X MG RESISTOR 12k

Ω

1/16W J

R245 NRSA63J-184X MG RESISTOR 180k

Ω

1/16W J

R246 NRSA63J-223X MG RESISTOR 22k

Ω

1/16W J

R247 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R248 NRSA63J-221X MG RESISTOR 220

Ω

1/16W J

R301 NRSA63J-102X MG RESISTOR 1k

Ω

1/16W J

R321 NRSA63J-821X MG RESISTOR 820

Ω

1/16W J

R322 NRSA63J-101X MG RESISTOR 100

Ω

1/16W J

R323 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R331 NRSA63J-821X MG RESISTOR 820

Ω

1/16W J

R332 NRSA63J-101X MG RESISTOR 100

Ω

1/16W J

R333 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R341 NRSA63J-821X MG RESISTOR 820

Ω

1/16W J

R342 NRSA63J-101X MG RESISTOR 100

Ω

1/16W J

R343 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R351 NRSA63J-821X MG RESISTOR 820

Ω

1/16W J

R352 NRSA63J-101X MG RESISTOR 100

Ω

1/16W J

R353 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R401 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R403 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

R404 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R405 NRSA63J-101X MG RESISTOR 100

Ω

1/16W J

R406 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R407 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R408 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R409 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R410 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R411 NRSA63J-470X MG RESISTOR 47

Ω

1/16W J

R412 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R413 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R414 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R415 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R416 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R417 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R418 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

R419 NRSA63J-223X MG RESISTOR 22k

Ω

1/16W J

R420 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R422 NRSA63J-225X MG RESISTOR 2.2M

Ω

1/16W J

R423 NRSA63J-470X MG RESISTOR 47

Ω

1/16W J

R424 NRSA63J-221X MG RESISTOR 220

Ω

1/16W J

R425 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

R426 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

R427 NRSA63J-682X MG RESISTOR 6.8k

Ω

1/16W J

R440 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R461 NRSA02J-101X MG RESISTOR 100

Ω

1/10W J

R462 NRSA02J-101X MG RESISTOR 100

Ω

1/10W J

R463 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

R464 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R481 NRSA02J-181X MG RESISTOR 180

Ω

1/10W J

R501 NRSA63J-333X MG RESISTOR 33k

Ω

1/16W J

R502 NRSA63J-822X MG RESISTOR 8.2k

Ω

1/16W J

R503 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

R504 NRSA63J-153X MG RESISTOR 15k

Ω

1/16W J

R507 NRSA63J-682X MG RESISTOR 6.8k

Ω

1/16W J

R508 NRSA63J-302X MG RESISTOR 3k

Ω

1/16W J

R509 NRSA63J-123X MG RESISTOR 12k

Ω

1/16W J

R510 NRSA63J-822X MG RESISTOR 8.2k

Ω

1/16W J

R511 NRSA63J-152X MG RESISTOR 1.5k

Ω

1/16W J

R512 NRSA63J-152X MG RESISTOR 1.5k

Ω

1/16W J

R513 NRSA63J-152X MG RESISTOR 1.5k

Ω

1/16W J

R514 NRS181J-220X MG RESISTOR 22

Ω

1/8W J

R515 NRS181J-220X MG RESISTOR 22

Ω

1/8W J

R516 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

R517 NRSA63J-512X MG RESISTOR 5.1k

Ω

1/16W J

R518 NRSA63J-822X MG RESISTOR 8.2k

Ω

1/16W J



Symbol

No.

Part No. Part Name Description Local
