JVC KD-R885BTS

ENGLISH
24
AUDIO SETTINGS
KD-R780BT :
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
REAR/REAR Rear speakers output
REAR/SUB.W (default) Subwoofer output
SUB.W/SUB.W Subwoofer output
Connection via speaker leads
For connections without using an external amplifier. However, with this
settings you can also enjoy the subwoofer output.
( 35, 36)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR Rear speakers output Rear speakers output
REAR/SUB.W Rear speakers output Rear speakers output
SUB.W/SUB.W Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[120HZ] is selected in [SUBWOOFER LPF] and [THROUGH] is not available.
–
[POSITION R02] is selected in [FADER] and selectable range is [POSITION
R15]
to [POSITION 00] .
Speaker output settings [SPK/PRE OUT]
(Applicable only if [X ' OVER TYPE ] is set to [2-WAY]) (
23)
Select the output setting for the speakers [ SPK/PRE OUT], based on the
speaker connection method.
Connection via lineout terminals
For connections through an external amplifier. ( 35, 36)
KD-R985BTS
/ KD-R885BTS :
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR SW
REAR/REAR (default) Front speakers
output
Rear speakers output Subwoofer output
REAR/SUB.W ( Not available ) ( Not available ) ( Not available )
SUB.W/SUB.W Front speakers
output
L (left): Subwoofer
output
R (right): (Mute)
Subwoofer output
KD-RD98BTS / KD-RD88BT :
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR/SW
REAR/REAR Front speakers output Rear speakers output
REAR/SUB.W (default) Front speakers output Subwoofer output
SUB.W/SUB.W Front speakers output Subwoofer output
