KD-S595
(No.49768)1-33
42 RELAY Power supply control terminal
43 BLKCL Sub code/ Block signal input terminal
44 BEEP Non connect
45 SW1 Detection switch 1
46 SW2 Detection switch 2
47 PSW Pnael switch detection
48 REST Rest switch input terminal
49 FLOCK Focus signal input terminal
50 TLOCK Tracking signal input terminal
51 CD SENSE Senser signal input terminal from CD LSI
52 STATUS Status signal input terminal
53 P.SAVE2 Power save 2 detection signal input termianl
54 SD/ST Station detect/Stereo indocator
55 REMOCON Remocon signal detection terminal
56 J BUS INT Non connect
57 BAND FM/AM band select terminal
58 MONO FM mono control signal output termianl
59 IFRQ/AGC FA auto serch IF request output
60 MUTE Mute switch
61 LEVEL Non connect
62 S METER S meter input terminal
63 KEY CHANGE AD key select terminal
64 KEY2 Key AD input terminal 2
65 KEY1 Key AD input terminal 1
66 KEY0 Key AD input terminal 0
67 P.SAVE1 Power save 1 detection input terminal
68 SENSE Senser signal output terminal
69 NC Non connect
70 FM IF COUNT FM IF control signal input terminal
71,72 NC Non connect
73 Vdd Power supply
74 AM OSC Non connect
75 FM OSC FM local osc signal input terminal
76 Vss GND
77 NC Non connect
78 EQ PLL error signalinput terminal
79 TEST1 Test terminal 1
80 XOUT X'tal oscillator connect terminal
Pin No. Symbol Function
