KD-S595
3-10
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 02
A
C 601 NCB31HK-223X C CAPACITOR
C 602 NCS31HJ-681X C CAPACITOR
C 603 NBE20JM-106X TS E CAP SVB20J
CJ601 VMC0335-001 CONNECTOR
D 601 SML-310VT/JK/-X LED
VOL+ R LED
D 602 SML-310VT/JK/-X LED
VOL- R LED
D 603 SML-310VT/JK/-X LED
LOUD R LED
D 604 SML-310VT/JK/-X LED
SEL R LED
D 605 SML-310VT/JK/-X LED
DISP R LED
D 606 SML-310VT/JK/-X LED
1 R LED
D 607 SML-310VT/JK/-X LED
2 R LED
D 608 SML-310VT/JK/-X LED
3 R LED
D 609 SML-310VT/JK/-X LED
4 R LED
D 610 SML-310VT/JK/-X LED
5 R LED
D 611 SML-310VT/JK/-X LED
6 R LED
D 612 SML-310VT/JK/-X LED
MODE R LED
D 613 LT1F67AF-W LED
SCM G LED
D 614 SML-310VT/JK/-X LED
EJECT R LED
D 615 SML-310VT/JK/-X LED
FM R LED
D 616 SML-310VT/JK/-X LED
CD R LED
D 617 SML-310VT/JK/-X LED
AM R LED
D 618 SML-310VT/JK/-X LED
UP R LED
D 619 SML-310VT/JK/-X LED
DOWN R LED
D 620 SML-310LT/MN/-X LED
POWER R LED
D 641 UDZS5.1B-X Z DIODE
D 643 1SS355-X DIODE
D 645 UDZS6.2B-X SI DIODE
D 731 NSPW310BS/BRS/ LED
D 732 NSPW310BS/BRS/ LED
IC601 PT6523LQ IC
R 601 NRSA63J-681X MG RESISTOR
R 602 NRSA63J-561X MG RESISTOR
R 603 NRSA63J-681X MG RESISTOR
R 604 NRSA63J-911X MG RESISTOR
R 605 NRSA63J-122X MG RESISTOR
R 606 NRSA63J-681X MG RESISTOR
R 607 NRSA63J-561X MG RESISTOR
R 608 NRSA63J-681X MG RESISTOR
R 609 NRSA63J-911X MG RESISTOR
R 610 NRSA63J-122X MG RESISTOR
R 611 NRSA63J-152X MG RESISTOR
R 612 NRSA63J-681X MG RESISTOR
R 613 NRSA63J-561X MG RESISTOR
R 614 NRSA63J-681X MG RESISTOR
R 615 NRSA63J-911X MG RESISTOR
R 616 NRSA63J-122X MG RESISTOR
R 617 NRSA63J-152X MG RESISTOR
R 631 NRSA02J-821X MG RESISTOR
R 632 NRSA02J-222X MG RESISTOR
R 633 NRSA02J-222X MG RESISTOR
R 634 NRSA02J-102X MG RESISTOR
R 635 NRSA02J-102X MG RESISTOR
R 636 NRSA02J-122X MG RESISTOR
R 637 NRSA02J-122X MG RESISTOR
R 638 NRSA02J-391X MG RESISTOR
R 639 NRSA02J-391X MG RESISTOR
R 640 NRSA02J-391X MG RESISTOR
R 641 NRSA02J-391X MG RESISTOR
R 642 NRSA02J-681X MG RESISTOR
R 643 NRSA02J-681X MG RESISTOR
R 644 NRSA02J-102X MG RESISTOR
R 645 NRSA02J-102X MG RESISTOR
R 651 NRSA63J-222X MG RESISTOR
R 652 NRSA63J-222X MG RESISTOR
R 653 NRSA63J-103X MG RESISTOR
R 654 NRSA63J-103X MG RESISTOR
R 655 NRSA63J-103X MG RESISTOR
R 656 NRSA63J-103X MG RESISTOR
R 657 NRSA63J-513X MG RESISTOR
R 658 NRSA63J-184X MG RESISTOR
R 731 NRS181J-681X MG RESISTOR
R 732 NRS181J-681X MG RESISTOR
S 601 NSW0066-001X TACT SW
S 602 NSW0066-001X TACT SW
S 603 NSW0066-001X TACT SW
S 604 NSW0066-001X TACT SW
S 605 NSW0066-001X TACT SW
S 606 NSW0066-001X TACT SW
S 607 NSW0066-001X TACT SW
S 608 NSW0066-001X TACT SW
S 609 NSW0066-001X TACT SW
S 610 NSW0066-001X TACT SW
S 611 NSW0066-001X TACT SW
S 612 NSW0066-001X TACT SW
S 613 NSW0066-001X TACT SW
S 614 NSW0066-001X TACT SW
S 615 NSW0066-001X TACT SW
S 616 NSW0066-001X TACT SW
S 617 NSW0066-001X TACT SW
S 618 NSW0066-001X TACT SW
S 619 NSW0066-001X TACT SW
S 620 NSW0066-001X TACT SW
