KD-S723R/KD-S721R
3-11
Item
Parts number Parts name Ar
a
Electrical parts list (Front board)
Remarks
Block No. 02
A
C 601 NCB31HK-223X C CAPACITOR
C 602 NCS31HJ-681X C CAPACITOR
C 603 NBE20JM-106X TS E CAP SVB20J
CJ601 VMC0335-001 CONNECTOR
D 601 SML-310DT/KL/-X LED KD-S723R
D 601 LNJ308G81/1-3/X LED KD-S721R
D 602 LNJ308G81/1-3/X LED KD-S721R
D 602 SML-310DT/KL/-X LED KD-S723R
D 603 SML-310DT/KL/-X LED KD-S723R
D 603 LNJ308G81/1-3/X LED KD-S721R
D 604 LNJ308G81/1-3/X LED KD-S721R
D 604 SML-310DT/KL/-X LED KD-S723R
D 605 SML-310DT/KL/-X LED KD-S723R
D 605 LNJ308G81/1-3/X LED KD-S721R
D 606 LNJ308G81/1-3/X LED KD-S721R
D 606 SML-310DT/KL/-X LED KD-S723R
D 607 LNJ308G81/1-3/X LED KD-S721R
D 607 SML-310DT/KL/-X LED KD-S723R
D 608 LNJ308G81/1-3/X LED KD-S721R
D 608 SML-310DT/KL/-X LED KD-S723R
D 609 LNJ308G81/1-3/X LED KD-S721R
D 609 SML-310DT/KL/-X LED KD-S723R
D 610 LNJ308G81/1-3/X LED KD-S721R
D 610 SML-310DT/KL/-X LED KD-S723R
D 611 SML-310DT/KL/-X LED KD-S723R
D 611 LNJ308G81/1-3/X LED KD-S721R
D 612 LNJ308G81/1-3/X LED KD-S721R
D 612 SML-310DT/KL/-X LED KD-S723R
D 613 SML-310VT/JK/-X LED KD-S721R
D 613 LNJ308G81/1-3/X LED KD-S723R
D 614 SML-310DT/KL/-X LED KD-S723R
D 614 LNJ308G81/1-3/X LED KD-S721R
D 615 LNJ308G81/1-3/X LED KD-S721R
D 615 SML-310DT/KL/-X LED KD-S723R
D 616 SML-310DT/KL/-X LED KD-S723R
D 616 LNJ308G81/1-3/X LED KD-S721R
D 617 LNJ308G81/1-3/X LED KD-S721R
D 617 SML-310DT/KL/-X LED KD-S723R
D 618 SML-310DT/KL/-X LED KD-S723R
D 618 LNJ308G81/1-3/X LED KD-S721R
D 619 LNJ308G81/1-3/X LED KD-S721R
D 619 SML-310DT/KL/-X LED KD-S723R
D 620 SML-310LT/MN/-X LED
D 641 UDZS5.1B-X ZENER DIODE
D 642 1SS355-X DIODE
D 643 1SS355-X DIODE
D 645 UDZS5.1B-X ZENER DIODE
IC601 LC75823W IC
PL601 QLL0056-001 PILOT LAMP KD-S721R
PL601 QLL0075-001 PILOT LAMP KD-S723R
PL602 QLL0075-001 PILOT LAMP KD-S723R
PL602 QLL0056-001 PILOT LAMP KD-S721R
R 601 NRSA63J-821X MG RESISTOR
R 602 NRSA63J-821X MG RESISTOR
R 603 NRSA63J-122X MG RESISTOR
R 604 NRSA63J-182X MG RESISTOR
R 605 NRSA63J-272X MG RESISTOR
R 606 NRSA63J-821X MG RESISTOR KD-S723R
R 606 NRSA02J-821X MG RESISTOR KD-S721R
R 607 NRSA02J-821X MG RESISTOR KD-S721R
R 607 NRSA63J-821X MG RESISTOR KD-S723R
R 608 NRSA63J-122X MG RESISTOR KD-S723R
R 608 NRSA02J-122X MG RESISTOR KD-S721R
R 609 NRSA02J-182X MG RESISTOR KD-S721R
R 609 NRSA63J-182X MG RESISTOR KD-S723R
R 610 NRSA63J-272X MG RESISTOR
R 611 NRSA63J-392X MG RESISTOR
R 612 NRSA63J-821X MG RESISTOR
R 613 NRSA63J-821X MG RESISTOR
R 614 NRSA63J-122X MG RESISTOR
R 615 NRSA63J-182X MG RESISTOR
R 616 NRSA63J-272X MG RESISTOR
R 617 NRSA63J-392X MG RESISTOR
R 631 NRSA02J-821X MG RESISTOR
R 632 NRSA02J-821X MG RESISTOR
R 633 NRSA02J-821X MG RESISTOR
R 634 NRSA02J-511X MG RESISTOR
R 635 NRSA02J-511X MG RESISTOR
R 636 NRSA02J-152X MG RESISTOR KD-S723R
R 636 NRSA02J-122X MG RESISTOR KD-S721R
R 637 NRSA02J-122X MG RESISTOR KD-S721R
R 637 NRSA02J-152X MG RESISTOR KD-S723R
R 638 NRSA02J-271X MG RESISTOR KD-S723R
R 638 NRSA02J-221X MG RESISTOR KD-S721R
R 639 NRSA02J-221X MG RESISTOR KD-S721R
R 639 NRSA02J-271X MG RESISTOR KD-S723R
R 640 NRSA02J-271X MG RESISTOR KD-S723R
R 640 NRSA02J-221X MG RESISTOR KD-S721R
R 641 NRSA02J-221X MG RESISTOR KD-S721R
R 641 NRSA02J-271X MG RESISTOR KD-S723R
R 642 NRSA02J-511X MG RESISTOR
R 643 NRSA02J-511X MG RESISTOR
R 644 NRSA02J-821X MG RESISTOR
R 645 NRSA02J-821X MG RESISTOR
R 651 NRSA63J-222X MG RESISTOR
R 652 NRSA63J-222X MG RESISTOR
R 653 NRSA63J-103X MG RESISTOR
R 654 NRSA63J-103X MG RESISTOR
R 655 NRSA63J-103X MG RESISTOR
R 656 NRSA63J-103X MG RESISTOR
R 657 NRSA63J-513X MG RESISTOR
R 658 NRSA63J-184X MG RESISTOR
S 601 NSW0066-001X TACT SWITCH POWER
S 602 NSW0066-001X TACT SWITCH VOL-
S 603 NSW0066-001X TACT SWITCH VOL+
S 604 NSW0066-001X TACT SWITCH LOUD
S 605 NSW0066-001X TACT SWITCH DISP
S 606 NSW0066-001X TACT SWITCH 1
S 607 NSW0066-001X TACT SWITCH SELECT
S 608 NSW0066-001X TACT SWITCH 2
S 609 NSW0066-001X TACT SWITCH 3
S 610 NSW0066-001X TACT SWITCH 4
S 611 NSW0066-001X TACT SWITCH 5
S 612 NSW0066-001X TACT SWITCH EJECT
S 613 NSW0066-001X TACT SWITCH UP
S 614 NSW0066-001X TACT SWITCH 6
S 615 NSW0066-001X TACT SWITCH MODE
S 616 NSW0066-001X TACT SWITCH SCM
S 617 NSW0066-001X TACT SWITCH DOWN
S 618 NSW0066-001X TACT SWITCH AM
S 619 NSW0066-001X TACT SWITCH FM
S 620 NSW0066-001X TACT SWITCH CD
