JVC KD-SX38MBT User Manual

20
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Audio Settings
Speaker output settings [SPK/PRE OUT]
(Applicable only if [X ' OVER TYPE ] is set to [2-WAY]) (page19)
Select the output setting for the speakers [SPK/PRE OUT] , based on the speaker
connection method.
Connection via lineout terminals
For connections through an external amplifier (Page32)
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
[REAR/REAR] Rear speakers output
[REAR/SUB.W] (default) Subwoofer output
[SUB.W/SUB.W] Subwoofer output
Connection via speaker leads
You can also connect the speakers without using an external amplifier
but still being able to enjoy the subwoofer output with these settings.
(Page31)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
[REAR/REAR] Rear speakers output Rear speakers output
[REAR/SUB.W] Rear speakers output Rear speakers output
[SUB.W/SUB.W] Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[120HZ] is selected in [SUBWOOFERLPF] and [THROUGH] is not available.
(Page22)
–
[POSITION R02] is selected in [FADER] and selectable range is [POSITION R15] to
[POSITION 00] . (Page19)
KD-SX38MBT_K_B5A-4237-00_EN_1st Draft.indd 20KD-SX38MBT_K_B5A-4237-00_EN_1st Draft.indd 20 27/4/2022 12:01:10 PM27/4/2022 12:01:10 PM
