KT-DB1000
5
56 DABDATX O FIC packet data stream outout data output terminal
57 MPUEN O DAB MPU interface chip enable output terminal
58 MPUMOD O DAB MPU interface mode signal outpout terminal
59 DZFINL I DZFL input terminal from DAC, "H" outout AMUTEL
60 DZFINR I DZFL input terminal from DAC, "H" outout AMUTER
61 AGND - Analogue GND terminal
62 AUDSEL O Audio signal select output terminal, "L" DAB "H" CD changer
63 AMUTEL O L-CH mute output terminal, "H" L-CH mute
64 AMUTER O R-CH mute output terminal, "H" R-CH mute
65 ANT+BIN I Antenna power supply voltage monitoer input terminal
66 VDD - Power supply
67 - - Not use
68 DACRST O DAC rest resr output terminal, "L" reset
69 - - Not use
70 SDCK I DAB serial data clock input terminal
71 SDDA I DAB serial data input terminal
72 SDWD I DAB sericl data window input terminal
73 SIFDA I/O On board serial write data input/output terminal pullup
74 SIFCK I On board serial write clock input terminal pullup
75 - - Not use
76 WFIC I Interrupt inout from DAB LSI, "L" triger detect
77 NIRQ I DDOWFIC input terminal from DABSEL
78 JBUSINT I JBUS interrupt input
79 PSAVE1 I PSAVE1(power off)input interrupt triger detect at "L" level
80 PSAVE2 O PSAVE2(STOP mode) input
81 POWOUT O Power on output terminal, "H" power on
82 RESET I Reset input terminal, "L" reset
83 VDD - POwer supply terminal
84 INDOUT0 O Indicator output 0 for test
85 INDOUT1 O Indicator output 1 for test
86 INDOUT2 O Indicator output 2 for test
87 INDOUT3 O Indicator output 3 for test
88 INDOUT4 O Indicator output 4 for test
89 INDOUT5 O Indicator output 5 for test
90 INDOUT6 O Indicator output 6 for test
91 INDOUT7 O Indicator output 7 for test
92 GND - GND terminal
93 DACCDTO O DAC chip select output
94 DACCCLK O DAC control clock output
95 DACCSN O DAC control data output
96~100 - - Not use
No. Symbol I/O Function
