JVC LT-37DS6BJ Service Manual

1-2 (No.YA299)
SPECIFICATION
Design & specifications are subject to change without notice.
Items Contents
Dimensions ( W × H × D ) 92.6 cm × 68.9 cm × 29.7 cm [Included stand]
92.6 cm × 63.1 cm × 10.8 cm [TV only]
Mass 26.0 kg [Included stand]
20.9 kg [TV only]
Power Input AC110V - AC240 V, 50 Hz / 60 Hz
Power Consumption 183 W (Standby: 2.6 W)
TV RF System Analog
Digital
CCIR (I)
DVB-T
Colour System PAL / NTSC 3.58/4.43 [EXT only]
Stereo System NICAM (I)
Receiving Frequency Analog
Digital
UHF: 470 MHz - 862 MHz
UHF: 474 MHz - 850 MHz
Intermediate
Frequency
VIF
SIF
38.9 MHz (I)
32.9 MHz (6.0 MHz :I)
Colour Sub
Carrier Frequency
PAL
NTSC
4.43 MHz
3.58 MHz / 4.43 MHz
Teletext System Analog
Digital
FLOF (Fastext level 2.5), WST(World Standard system)
MHEG 5 UK profile
LCD panel 37V-inch wide aspect (16 : 9)
Screen Size Diagonal : 94.9 cm (H: 82.6 cm × V: 46.7 cm)
Display Pixels Horizontal : 1366 dots × Vertical : 768 dots (W-XGA)
Audio Power Output 10 W + 10 W
Speaker 6.6 cm, round type × 2 (Oblique corn)
Aerial terminal (VHF/UHF) 75 Ω unbalanced, coaxial
EXT-1 / EXT-2 (Input / Output) 21-pin Euro connector (SCART socket ) × 2
EXT-3 (Input) S-Video
Video
Audio
Mini-DIN 4 pin × 1
Y: 1 V (p-p), Positive (Negative sync provided), 75 Ω
C: 0.286 V (p-p) (Burst signal), 75 Ω
1 V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack × 1
500 mV (rms), High impedance, RCA pin jack × 2
EXT-4 (Input) Component Video
1125i
625p / 525p / 625i / 525i
Audio
RCA pin jack × 3
Y : 1 V (p-p) (Sync signal: ±0.35V(p-p), 3-value sync.), 75Ω
Pb/Pr : ±0.35V(p-p), 75 Ω
Y : 1 V (p-p), Positive (Negative sync provided), 75 Ω
Cb/Cr : 0.7V(p-p), 75 Ω
500 mV(rms) (-4dBs), high impedance, RCA pin jack × 2
HDMI Input Video
Audio
HDMI connector × 1
(Digital-input terminal is not compatible with picture signals of computer signal)
Digital: HDMI connector × 1
Anarog: 500mV(rms) (-4dBs), high impedance, RCA pin jack × 2
PC (RGB) Input D-sub 15 pin × 1
R/G/B : 0.7 V (p-p), 75Ω
HD / VD : 1 V (p-p) to 5 V (p-p), high impedance
< Available signal >
VGA : 640 pixels × 480 pixels (Horizontal : 31.5 kHz / Vertical : 60 Hz)
XGA : 1024 pixels × 768 pixels (Horizontal : 48.4 kHz / Vertical : 60 Hz)
Audio output 500 mV (rms), Low impedance, RCA pin jack × 2
Headphone 3.5 mm stereo mini jack × 1
Remote Control Unit RM-C1813H (AA/R6 dry cell battery × 2)
