4.6 INITIAL SETTING VALUES IN THE SERVICE MODE
• Perform fine-tuning based on the "initial values" using the remote control when in the Service mode.
• The "initial values" serve only as an indication rough standard and therefore the values with which optimal display can be achieved
may be different from the default values. But, don't change the values that are not written in "ADJUSTMENT PROCEDURE". They
are fixed values.
4.6.1 VIDEO SYSTEM SETTING 4.6.2 AUDIO SYSTEM SETTING (*Fixed values)
4.6.3 PANEL CONTOROL SYSTEM SETTING (*Fixed values)
4.6.4 DRIVE SYSTEM SETTING (*Fixed values)
Item No. Item name Variable range Setting value
S001 PREPARE 0 - 31 0
S002 NTSC BL 0 - 15 0
S003 NTSC CNT 0 - 255 53
S004 NT CR OF 0 - 15 6
S005 NT CB OF 0 - 15 6
S006 525i BL 0 - 15 0
S007 525i CNT 0 - 255 53
S008 5i CB OF 0 - 15 0
S009 5i CR OF 0 - 15 0
S010 5i CR GN 0 - 15 6
S011 5i CB GN 0 - 15 6
S012 HD BL 0 - 63 61
S013 HD CB OF 0 - 63 59
S014 HD CR OF 0 - 63 55
S015 RT CONT 0 - 15 7
S016 RT CB OF 0 - 15 6
S017 RT CR OF 0 - 15 6
S018 RT CL GA 0 - 15 1
S019 PC CL MB 0 - 7 0
S020 PC CL LB 0 - 31 0
S021 PC CL MR 0 - 71 0
S022 PC CL LR 0 - 31 0
S023 (Not display) 0 - 255 0
S024 (Not display) 0 - 255 0
S025 (Not display) 0 - 255 0
S026 (Not display) 0 - 255 0
S027 (Not display) 0 - 255 0
S028 (Not display) 0 - 255 0
S029 (Not display) 0 - 255 0
S030 R DRIVE 0 - 255 133
S031 G DRIVE 0 - 255 132
S032 B DRIVE 0 - 255 109
S033 (Not display) 0 - 255 0
S034 (Not display) 0 - 255 0
S035 (Not display) 0 - 255 0
S036 (Not display) 0 - 255 0
S037 (Not display) 0 - 255 0
S038 (Not display) 0 - 255 0
S039 ILA COM 0 - 1 0
Item No. Item name Variable range Setting value
T001 IN LEVEL 0 - 255 0
T002 LOW SEP 0 - 255 0
T003 HIGH SEP 0 - 255 0
T004 AFC 0 - 255 0
T005 (Not display) 0 - 255 0
T006 ATT V ON 0 - 1 0
T007 ATT U ON 0 - 1 0
T008 ATT C ON 0 - 1 0
T009 (Not display) 0 - 255 0
T010 (Not display) 0 - 255 0
Item No. Item name Variable range Setting value
P001 TM HOR H 00 - FF 00
P002 TM HOR L 00 - FF 00
P003 TM MIN 00 - FF 00
P004 TEMP0 0 - 255 0
P005 (Not display) 0 - 255 0
P006 (Not display) 0 - 255 0
P007 (Not display) 0 - 255 0
P008 (Not display) 0 - 255 0
P009 (Not display) 0 - 255 0
P010 (Not display) 0 - 255 0
Item No. Item name Variable range Setting value
D001 SLV GN 00 - 3F 20
D002 SLVH GN 00 - 3F 20
D003 SLH GN 00 - 3F 20
D004 SLV Pf 00 - 03 01
D005 SLH Pf H 00 - 01 01
D006 SLH Pf L 00 - 03 01
D007 SL EGCON 00 - 3F 08
D008 SL EGONF 00 - 01 01
D009 SL CRGON 00 - 3F 03
D010 SL CRGON 00 - 01 01
D011 SL ON OF 00 - 01 01
D012 SV GN 00 - 3F 0D
D013 SVH GN 00 - 3F 16
D014 SH GN 00 - 3F 16
D015 SV Pf 00 - 03 01
D016 SV PfH 00 - 01 01
D017 SV PfL 00 - 03 01
D018 SYL CON 00 - 3F 20
D019 SYL CONF 00 - 01 01
