JVC LT-37X688 Service Manual

1-26 (No.YA535)
C036 TEST REG4 0H - FFH - - - - - E8H
C037 OFST_HLD_DUR 0 - 255 - - - - - 50
C038 OFST_HLD_DUR_CYC_1 0 - 255 - - - - - 0
C039 OFST_HLD_DUR_CYC_2 0 - 255 - - - - - 0
C040 OFST_HLD_MODE 0 - 255 - - - - - 0
C041 SOG FILTER ENABLE 0 - 1 - - - - - - - - -
C042 VCO GEAR SELECT 0 - 1 - - - - - - - - -
C043 AUTO GAIN MATCHING 00 - FF - - - - - - - - -
C044 OFST HLD BUSY WAIT 0 - 255 - - - - - 116 0 0 0
X001 H PIX L 0H - FFH 97H
X002 H PIX H 0H - FFH 8H
X003 V LINE L 0H - FFH 64H
X004 V LINE H 0H - FFH 4H
X005 X STRT L 0H - FFH C0H
X006 X STRT H 0H - FFH 0H
X007 X END L 0H - FFH 3FH
X008 X END H 0H - FFH 8H
X009 Y STRT L 0H - FFH 28H
X010 Y STRT H 0H - FFH 0H
X011 Y END L 0H - FFH 5FH
X012 Y END H 0H - FFH 4H
X013 HYSNC W 0H - FFH 2DH
X014 VSYNC W 0H - FFH 5H
X015 HSYNC P 0H - FFH 0H
X016 VSYNC P 0H - FFH 0H
X017 INTERLACE ENABLE 0H - FFH 1H
X018 PIXEL CLOCK 0 0H - FFH 6H
X019 PIXEL CLOCK 1 0H - FFH D5H
X020 PIXEL CLOCK 2 0H - FFH 6BH
X021 PIXEL CLOCK 3 0H - FFH 4H
X022 PMON PIXEL CLOCK 0 0H - FFH 6H
X023 PMON PIXEL CLOCK 1 0H - FFH D5H
X024 PMON PIXEL CLOCK 2 0H - FFH 6BH
X025 PMON PIXEL CLOCK 3 0H - FFH 4H
X026 PMON GR ADJUST X L 0H - FFH 0H
X027 PMON GR ADJUST X H 0H - FFH 0H
X028 PMON GR ADJUST Y L 0H - FFH 0H
X029 PMON GR ADJUST Y H 0H - FFH 0H
X101 RED GAIN NTSC 0 - 200 100 - - - - 100
X102 GREEN GAIN NTSC 0 - 200 100 - - - - 100
X103 BLUE GAIN NTSC 0 - 200 100 - - - - 100
X104 RED GAIN COMP SD 0 - 200 - - - - - 100 - -
X105 GREEN GAIN COMP SD 0 - 200 - - - - - 100 - -
X106 BLUE GAIN COMP SD 0 - 200 - - - - - 100 - -
Item No. Item Variable range
Setting value
RF CVS ATSC HDMI PV
COMPONENT
480i 480p 1080i 720p

JVC LT-37X688 Specifications

General

Integrated clock	Yes
Comb filter	Digital
Display diagonal	37 \
Display brightness	500 cd/m²
Native aspect ratio	16:9
Viewing angle, horizontal	176 °
Analog signal format system	NTSC
HDCP	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video outputs quantity	1
Product color	Black
RMS rated power	20 W

Weight and Dimensions

Depth (without stand)	232 mm
Width (without stand)	927.1 mm
Height (without stand)	654.05 mm
Weight (without stand)	18280 g
