USER MANUAL
DLP PROJECTOR
LX-WX50

Table of Contents

Questions and Answers

  • J
    Jose GallegosAug 4, 2025
    What to do if my JVC LX-WX50 Dlp projector does not turn on?
    • B
      Breanna MasonAug 4, 2025
      If your JVC Dlp projector isn't turning on, there are a few potential reasons. First, ensure the power cable is securely plugged into both the projector's AC inlet and a working power outlet, and that the outlet switch is on, if applicable. Also, if the projector is cooling down, wait for the process to complete before attempting to turn it on again. Finally, make sure the lamp cover is correctly and securely attached.
  • A
    Angela MercerAug 9, 2025
    Why is there no picture on my JVC Dlp projector?
    • I
      Ian MccannAug 9, 2025
      If you're not getting a picture on your JVC Dlp projector, the issue could be with the video source or the projector's input selection. Ensure that the video source is turned on and the signal cable is properly connected. Also, verify that the projector is correctly connected to the input source device. Finally, make sure you've selected the correct input source using the SOURCE key on either the projector or the remote control.
  • J
    jbeckerAug 14, 2025
    How to fix a JVC LX-WX50 Dlp projector remote that is not working?
    • H
      Holly BakerAug 14, 2025
      If your JVC Dlp projector remote isn't working correctly, try these solutions: 1. Replace the batteries with new ones. 2. Ensure there are no obstacles blocking the path between the remote and the projector. 3. Make sure you are within 8 meters (26.2 feet) of the projector.
  • D
    Daniel HaydenAug 18, 2025
    What to do if the picture on my JVC Dlp projector is blurred?
    • D
      David WilliamsAug 18, 2025
      If the picture on your JVC Dlp projector appears blurred, try these solutions: * Adjust the focus of the lens using the focus ring. * Adjust the projection angle, direction, and height of the projector to properly align it with the screen. * If your projector has a lens cover, make sure it's removed.
  • A
    Ashley KirkAug 25, 2025
    Why is 3D content not displaying correctly on my JVC LX-WX50 Dlp projector?
    • K
      Kevin SmithAug 25, 2025
      If 3D content isn't displaying correctly on your JVC Dlp projector, several factors could be the cause. First, ensure that your 3D glasses are charged. Next, verify that the settings in the 3D menu are correctly configured. Also, confirm that you are using a 3D Blu-ray Disc. Finally, check that the correct input source has been selected using the SOURCE key on the projector or remote control.
  • A
    Alexandra SawyerAug 28, 2025
    What causes an unstable image on a JVC LX-WX50?
    • D
      David WilsonAug 29, 2025
      An unstable image on your JVC Dlp projector is often due to loose cable connections. Ensure that all connection cables are securely connected to both the projector and the signal source at the appropriate terminals.

Summary

Safety Precautions

Regulatory Compliance and Declarations

FCC information, declaration of conformity, and noise emission statements.

Important Safety Instructions

Disposal of Equipment and Batteries

Guidance for environmentally responsible disposal of the projector and its batteries.

Overview

Shipping Contents

List of items included with the projector.

Projector Exterior View

Component Identification

Diagrams and labels for projector exterior parts and ports.

Controls and Functions

Projector Control Panel

Explanation of buttons and indicators on the projector's control panel.

Remote Control Operation

Remote Control Management

Battery and Range Guidelines

Instructions for battery replacement and effective remote control range.

Installation

Choosing an Installation Location

Factors and methods for selecting an installation site for the projector.

Projected Image Size and Dimensions

Projection Dimensions Table

Table and illustration for determining projection distance and image size.

Shifting the Projection Lens Vertically

Connection

Operation Procedures

Powering the Projector On and Off

Step-by-step guide for powering the projector on and off.

Selecting Input Sources

Adjusting the Projected Image

Image Adjustment Techniques

Using zoom, focus, angle, and auto-adjust for optimal picture.

Correcting Image Distortion

Keystone and Corner Correction

Manual adjustments for keystone and corner alignment.

Menu Functions Overview

OSD Menu Navigation

Introduction to accessing and using the projector's On-Screen Display menus.

DISPLAY Menu Options

Display Settings

Adjustments for screen color, aspect ratio, keystone, and corners.

Picture Position and 3 D Settings

Controls for image position, zoom, digital zoom, 3D, and 3D sync.

PICTURE Menu Options

Core Picture Adjustments

Settings for picture mode, brightness, contrast, color, and tint.

Advanced Picture Enhancements

Fine-tuning sharpness, color temperature, and 3D color management.

SOURCE and Basic System Setup

Source Selection & Basic Configuration

Managing inputs and basic system settings like timers and language.

Advanced System Setup

Advanced Setup Features

Panel lock, sleep timer, splash screen.

System Settings

Altitude, audio, menu, lamp, security, and caption settings.

LAN Settings and Information Menu

Network configuration and system status viewing.

Controlling the Projector Remotely

Configuring LAN Settings

Steps to set up network connectivity for remote control.

Controlling Projector via Web Browser (e-Control)

Web Interface Features

Recommended OS, tools page, and error status for web-based control.

Controlling Projector via PJLink

PJLink Functionality and Commands

Information on PJLink protocol, password, and supported commands.

Maintenance

Projector Care and Storage

Cleaning, storing, and transporting the projector.

Lamp Information and Management

Lamp Usage and Lifespan Extension

Checking lamp hour, extending life, and setting lamp mode/auto-off.

Timing of Lamp Replacement

Replacing the Lamp

Indicators

Troubleshooting

Specifications

Technical Specifications Overview

Details on optical, electrical, input/output, control, environmental, and mechanical aspects.

Dimensions

Timing Charts

Supported Timing for PC Input

Table of supported PC input resolutions and timings.

Supported Timing for HDMI (HDCP) Input

Table of supported HDMI input resolutions and timings.

Supported Timing for Component;Video Inputs

Tables for Component-YPbPr and S-Video/Video input timings.

Warranty and Copyright Information

Warranty, Copyright, and Disclaimer

Legal terms, warranty conditions, and copyright notices for the manual.

JVC LX-WX50 Specifications

General IconGeneral
Display TechnologyDLP
ResolutionWXGA
Native ResolutionWXGA (1280x800)
Contrast Ratio25000 : 1
Light SourceLamp
Lamp TypeUHP
Throw Ratio1.54 - 1.71:1
Weight3.3 kg
Projection Size30 - 300 inches
Input PortsHDMI, VGA, Composite, S-Video
Brightness4500 ANSI Lumens
Lamp Life5000 hours (Normal), 10000 hours (Eco)
Throw Distance1.2 - 10.2 m
