JVC MX-DK11A - Page 12

1-12 (No.MB598)
Parts list (Input board) [P3-14 Block No.02]
MX-DK11A/UY
Item Parts name
Parts number
Q'ty
MX-DK1US MX-DK11A/UY
IC300 IC SN74AHCT08NS-X TC74VHCT08AFT-X 1
IC325 IC KIA278R05PI PQ050RDC2SZF 1
IC410 IC NJM4565E-X ---------- 0
IC473 IC KTC812T-X ---------- 0
IC560 IC NJM4565E-X KIA4558F-X 1
IC600 IC KTC812T-X RT3Y97M-X 1
Q3100 DIGI TRANSISTOR KRA102S-X RT1P141C-X 1
Q3101 DIGI TRANSISTOR KRC102S-X RT1N141C-X 1
Q4080 DIGI TRANSISTOR KRA104S-X ---------- 0
Q4081 TRANSISTOR KTC2875-X ---------- 0
Q4730 DIGI TRANSISTOR KRA104S-X ---------- 0
Q5400 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q5401 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q5402 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q5500 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q5501 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q5502 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q5851 TRANSISTOR KTC3875/YG/-X RT1N240C-X 1
Q5853 TRANSISTOR KTC3875/YG/-X RT1N240C-X 1
Q6000 DIGI TRANSISTOR KRA104S-X ---------- 0
D3300 Z DIODE MTZJ5.1B-T2 ---------- 0
D6850 DIODE 1SS133-T2 ---------- 0
D6851 DIODE 1SS133-T2 ---------- 0
C3300 E CAPACITOR QETN1EM-476Z ---------- 0
C3302 C CAPACITOR ---------- NCB31CK-104X 1
C3251 E CAPACITOR QETN1EM-477Z QETN1CM-107Z 1
C3500 C CAPACITOR NDC31HJ-270X NDC31HJ-300X 1
C3501 C CAPACITOR NDC31HJ-270X NDC31HJ-300X 1
C4080 E CAPACITOR QETN1HM-106Z ---------- 0
C4081 C CAPACITOR NCB31EK-683X ---------- 0
C4082 E CAPACITOR QETN1HM-226Z ---------- 0
C4050 E CAPACITOR QTE1V28-107Z QTE1E46-107Z 1
C4100 E CAPACITOR QETN1HM-226Z ---------- 0
C4101 E CAPACITOR QETN1HM-106Z ---------- 0
C4200 E CAPACITOR QETN1HM-226Z ---------- 0
C4201 E CAPACITOR QETN1HM-106Z ---------- 0
C4705 E CAPACITOR QETN1JM-476Z ---------- 0
C4707 M CAPACITOR QFLC1HJ-473Z QFLC1HJ-333Z 1
C4708 M CAPACITOR QFG32AJ-332Z QFG32AJ-392Z 1
C4710 E CAPACITOR QTE1V06-106Z QTE1J46-106Z 1
C4711 E CAPACITOR QETN1HM-105Z QETN1HM-225Z 1
C4723 E CAPACITOR QETN1JM-476Z QTE1E53-107Z 1
C4730 E CAPACITOR QETN1HM-105Z ---------- 0
C4734 E CAPACITOR QETN1JM-476Z QTE1J46-106Z 1
C4736 E CAPACITOR QETN1JM-476Z QTE1J63-106Z 1
