JVC MX-DK11A - Page 21

(No.MB598)1-21
Parts list (Front board) [P3-19 Block No.03]
MX-DK11A
R6001 MG RESISTOR NRSA63J-103X ---------- 0
R6101 MG RESISTOR NRSA63J-103X ---------- 0
R6111 MG RESISTOR NRSA63J-103X ---------- 0
CN308 CONNECTOR QGF1210G1-07 QGF1205F2-07 1
K3002 INDUCTOR ---------- QQR0621-001Z 1
Item Parts name
Parts number
Q'ty
MX-DK1US MX-DK11A
IC950 ECHO IC PT2399-S-W ---------- 0
IC960 IC KIA4558F-X ---------- 0
IC970 IC ---------- KIA4558F-X 1
Q9530 TRANSISTOR KTC3875/YG/-X ---------- 0
Q9531 TRANSISTOR KTC3875/YG/-X ---------- 0
Q9532 TRANSISTOR KTC3875/YG/-X ---------- 0
Q9601 TRANSISTOR KTC3875/YG/-X ---------- 0
Q9602 TRANSISTOR KTC3875/YG/-X ---------- 0
D9500 Z DIODE MTZJ5.1B-T2 ---------- 0
D9521 Z DIODE MTZJ3.9B-T2 ---------- 0
D9522 Z DIODE MTZJ3.9B-T2 ---------- 0
D9523 Z DIODE MTZJ3.9B-T2 ---------- 0
D9601 Z DIODE 1SS133-T2 ---------- 0
D9602 Z DIODE 1SS133-T2 ---------- 0
D9651 Z DIODE ---------- MA111-X 1
D9652 Z DIODE ---------- MA111-X 1
D9653 Z DIODE UDZW2.4B-X ---------- 0
C9200 C CAPACITOR NCB31HK-103X ---------- 0
C9500 E CAPACITOR QEKC1CM-107Z ---------- 0
C9501 E CAPACITOR QEKC1CM-476Z ---------- 0
C9502 C CAPACITOR NCB31CK-104X ---------- 0
C9503 C CAPACITOR NCB31CK-104X ---------- 0
C9504 C CAPACITOR NCB31CK-823X ---------- 0
C9505 C CAPACITOR NCB31CK-823X ---------- 0
C9506 C CAPACITOR NCB31HK-103X ---------- 0
C9507 C CAPACITOR NCB31HK-561X ---------- 0
C9508 C CAPACITOR NCB31HK-332X ---------- 0
C9509 E CAPACITOR QEKC1CM-106Z ---------- 0
C9510 E CAPACITOR QEKC1CM-106Z ---------- 0
C9511 E CAPACITOR QEKC1HM-475Z ---------- 0
C9512 C CAPACITOR NCB31HK-561X ---------- 0
C9513 C CAPACITOR NCB31HK-392X ---------- 0
C9600 E CAPACITOR QEKC1AM-107Z ---------- 0
C9601 E CAPACITOR QEKC1HM-224Z ---------- 0
C9602 E CAPACITOR QEKC1HM-104Z ---------- 0
C9603 C CAPACITOR NCB31HK-104X ---------- 0
C9604 C CAPACITOR NCB31HK-681X ---------- 0
Item Parts name
Parts number
Q'ty
MX-DK1US MX-DK11UN
