JVC MX-DK11A - Page 24

1-24 (No.MB598)
MX-DK11UX/UG/UN
MX-DK11UY
Item Parts name
Parts number
Q'ty
MX-DK1US MX-DK11UX/UG/UN
Q9530 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q9531 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q9532 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q9601 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
Q9602 TRANSISTOR KTC3875/YG/-X 2SC3928A/QR/-X 1
C9200 C CAPACITOR NCB31HK-103X ---------- 0
C9631 C CAPACITOR NCB31HK-102X ---------- 0
C9633 C CAPACITOR NCB21HK-473X NCB31CK-473X 1
R9104 MG RESISTOR NRSA63J-0R0X NRSA63J-122X 1
R9105 MG RESISTOR NRSA63J-0R0X NRSA63J-152X 1
R9631 MG RESISTOR NRSA63J-472X ---------- 0
J962 JACK QNS0231-001 QNS0276-001 1
J980 JACK QNS0231-001 QNS0276-001 1
K9898 FERRITE BEADS NQR0505-001X NQR0627-004X 1
TW961 S.WIRE ---------- QUB220-05DMHP-E 1
TW962 S.WIRE QUB220-18HPDM-E QUB220-05DMHP-E 1
TW962 S.WIRE QUB220-18HPDM-E ---------- 0
Item Parts name
Parts number
Q'ty
MX-DK1US MX-DK11UY
IC950 ECHO IC PT2399-S-W ---------- 0
IC960 IC KIA4558F-X ---------- 0
IC970 IC ---------- KIA4558F-X 1
Q9530 TRANSISTOR KTC3875/YG/-X ---------- 0
Q9531 TRANSISTOR KTC3875/YG/-X ---------- 0
Q9532 TRANSISTOR KTC3875/YG/-X ---------- 0
Q9601 TRANSISTOR KTC3875/YG/-X ---------- 0
Q9602 TRANSISTOR KTC3875/YG/-X ---------- 0
D9601 Z DIODE 1SS133-T2 ---------- 0
D9602 Z DIODE 1SS133-T2 ---------- 0
D9651 Z DIODE ---------- MA111-X 1
D9652 Z DIODE ---------- MA111-X 1
D9653 Z DIODE UDZW2.4B-X ---------- 0
D9500 Z DIODE MTZJ5.1B-T2 ---------- 0
D9521 Z DIODE MTZJ3.9B-T2 ---------- 0
D9522 Z DIODE MTZJ3.9B-T2 ---------- 0
D9523 Z DIODE MTZJ3.9B-T2 ---------- 0
C9200 C CAPACITOR NCB31HK-103X ---------- 0
C9500 E CAPACITOR QEKC1CM-107Z ---------- 0
C9501 E CAPACITOR QEKC1CM-476Z ---------- 0
C9502 C CAPACITOR NCB31CK-104X ---------- 0
C9503 C CAPACITOR NCB31CK-104X ---------- 0
C9504 C CAPACITOR NCB31CK-823X ---------- 0
C9505 C CAPACITOR NCB31CK-823X ---------- 0
C9506 C CAPACITOR NCB31HK-103X ---------- 0
C9507 C CAPACITOR NCB31HK-561X ---------- 0
