JVC MX-DK11A - Page 7

(No.MB598)1-7
MX-DK11UX/UG
32 SCREW QYSBSG3016EA QYSBSG3016EA 1
35 SCREW QYSBSG3010EA ---------- 0
39 SCREW QYSBSF3010ZA ---------- 0
40 METAL COVER GV10217-007A/S/ GV10217-015A/S/ 1
44 REAR PANEL GV10324-004A GV10324-045A 1
47 TUNER QAU0412-001 QAU0492-001 1
58 TAP SCREW QYSDSG3006NA QYSDSG3008NA 2
64 POWER TRANS QQT0515-001 QQT0534-001 1
66 FFC WIRE QUQU12-1911AJ-E QUQU12-1913AJ-E 1
67 FFC WIRE QUQU12-1915BJ-E QUQU12-1921BJ-E 1
68 FFC WIRE QUQU12-0915BJ-E QUQU12-0921BJ-E 1
69 FFC WIRE QUR110-2520AJ-E QUR110-0532BJ-E 1
70 FFC WIRE QUR110-0515AJ-E QUR110-2517AJ-E 1
71 FFC WIRE QUR110-0532BJ-E QUR110-0513AJ-E 1
78 SPACER GV30349-048A ---------- 0
Item Parts name
Parts number
Q'ty
MX-DK1US MX-DK11UX/UG
1 FRONT PANEL ASSY GV10328-001A GV10328-037A 1
4 FUNCTION BUTTON GV20418-002A GV20418-003A 1
7 FRONT LENS GV10319-001A GV10319-017A 1
8 VOLUME KNOB GV30875-001A GV30875-007A 1
9 V.ORNAMENT ASSY GV30894-001A GV30894-004A 1
11 MIC.KNOB GV40083-004A GV40083-006A 1
14 SPACER GV30349-068A ---------- 0
24 TAP SCREW QYSBSF3010ZA QYSBSF3010ZA 5
29 SPACER GV30349-046A ---------- 0
31 HEAT SINK GV30879-003A GV31012-001A 1
32 SCREW QYSBSG3016EA QYSBSG3016EA 1
35 SCREW QYSBSG3010EA ---------- 0
39 SCREW QYSBSF3010ZA ---------- 0
40 METAL COVER GV10217-007A/S/ GV10217-015A/S/ 1
44 REAR PANEL GV10324-004A GV10324-046A 1
47 TUNER QAU0412-001 QAU0492-001 1
58 TAP SCREW QYSDSG3006NA QYSDSG3008NA 2
64 POWER TRANS QQT0515-001 QQT0534-001 1
66 FFC WIRE QUQU12-1911AJ-E QUQU12-1913AJ-E 1
67 FFC WIRE QUQU12-1915BJ-E QUQU12-1921BJ-E 1
68 FFC WIRE QUQU12-0915BJ-E QUQU12-0921BJ-E 1
69 FFC WIRE QUR110-2520AJ-E QUR110-0532BJ-E 1
70 FFC WIRE QUR110-0515AJ-E QUR110-2517AJ-E 1
71 FFC WIRE QUR110-0532BJ-E QUR110-0513AJ-E 1
78 SPACER GV30349-048A ---------- 0
Item Parts name
Parts number
Q'ty
MX-DK1US MX-DK11UW
