(No.MB598)1-9
Parts list (Power board) [P3-12 Block No.01]
MX-DK11A
64 POWER TRANS QQT0515-001 QQT0534-001 1
66 FFC WIRE QUQU12-1911AJ-E QUQU12-1913AJ-E 1
67 FFC WIRE QUQU12-1915BJ-E QUQU12-1921BJ-E 1
68 FFC WIRE QUQU12-0915BJ-E QUQU12-0921BJ-E 1
69 FFC WIRE QUR110-2520AJ-E QUR110-0532BJ-E 1
70 FFC WIRE QUR110-0515AJ-E QUR110-2517AJ-E 1
71 FFC WIRE QUR110-0532BJ-E QUR110-0513AJ-E 1
78 SPACER GV30349-048A ---------- 0
Item Parts name
Parts number
Q'ty
MX-DK1US MX-DK11A
Q1050 TRANSISTOR KTC3200/GL/-T KTC3199/GL/-T 1
Q1052 TRANSISTOR KTA1268/GL/-T KTA1267/YG/-T 1
Q1053 TRANSISTOR KTA1268/GL/-T KTA1267/YG/-T 1
Q1090 TRANSISTOR KTA1268/GL/-T KTA1267/YG/-T 1
Q1091 TRANSISTOR KTC1027/OY/-T KTC3200/GL/-T 1
Q1092 TRANSISTOR KTC3200/GL/-T KTC3199/GL/-T 1
Q1093 TRANSISTOR KTA1023/OY/-T KTA1268/GL/-T 1
Q2011 TRANSISTOR KTC3203/OY/-T KTC3199/GL/-T 1
D1041 SI DIODE 1SS133-T2 ---------- 0
D1042 SI DIODE 1SS133-T2 ---------- 0
D1105 DIODE 2A02-M ---------- 0
D1106 DIODE 2A02-M ---------- 0
C1001 E CAPACITOR QEZ0818-478 QEZ0808-478 1
C1002 E CAPACITOR QEZ0818-478 QEZ0808-478 1
C1010 E CAPACITOR QETM1EM-338 QETM1VM-338 1
C1011 E CAPACITOR QETM1EM-338 QETM1VM-338 1
C1083 E CAPACITOR QTE1V06-106Z QTE1J46-106Z 1
C1085 E CAPACITOR QTE1V06-106Z QTE1J46-106Z 1
C1091 M CAPACITOR QFZ0212-104Z QFVF1HJ-104Z 1
C1092 M CAPACITOR QFZ0212-104Z QFVF1HJ-104Z 1
C1221 E CAPACITOR QETM1EM-688 QETM1EM-478 1
C1222 E CAPACITOR QETM1CM-688 QETM1CM-478 1
C1270 E CAPACITOR QETN1HM-106Z ---------- 0
C1280 E CAPACITOR QETN1HM-106Z ---------- 0
C1290 E CAPACITOR QETN1HM-106Z ---------- 0
C1260 E CAPACITOR QETN1HM-106Z ---------- 0
C2019 M CAPACITOR QFLC1HJ-104Z QFVF1HJ-104Z 1
C2020 M CAPACITOR QFZ0227-104Z QFNC2AJ-104Z 1
C2200 M CAPACITOR QFZ0227-104Z QFZ0228-104Z 1
R1042 C RESISTOR QRE141J-272Y ---------- 0
R1043 C RESISTOR QRE141J-153Y ---------- 0
R1044 C RESISTOR QRE141J-272Y ---------- 0
R1045 C RESISTOR QRE141J-153Y ---------- 0
R1093 C RESISTOR QRE141J-103Y QRE141J-822Y 1
Item Parts name
Parts number
Q'ty
MX-DK1US MX-DK11UN
