MX-J200/J206
3-18
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 08
A
Item
Parts number Parts name Area
Remarks
A
C 351 GJ270192250310 E.CAPACITOR 50V VX M 2.2UF
C 352 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 353 GJ270114760310 E.CAPACITOR 10V M 47UF
C 354 GJ270124760310 E.CAPACITOR 16V M 47UF
C 355 GJ116229321 A.CAPACITOR 50V B K 820PF
C 357 GJ283111532432 CAPACITOR 100V K 0.015UF
C 359 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 360 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 361 GJ283116822432 CAPASITER 100V K 0.0068UF
C 362 GJ283115622432 CAPACITOR 100V K 0.0056UF
C 363 GJ283115622432 CAPACITOR 100V K 0.0056UF
C 364 GJ111067121 C.CAPACITOR 47000PF F Z 50V
C 365 GJ270111070310 E.CAPACITOR 10V M 100UF
C 369 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 370 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 371 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 372 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 373 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 401 GJ116229121 A.CAPACITOR 50V B K 560PF
C 402 GJ116229121 A.CAPACITOR 50V B K 560PF
C 403 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 404 GJ283111832432 CAPACITOR 100V K 0.018UF
C 405 GJ270111070310 E.CAPACITOR 10V M 100UF
C 406 GJ116228621 A.CAPACITOR 50V B K 220PF
C 407 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 408 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 409 GJ264261822101 A.CAPACITOR 16V X M 0.0018UF
C 410 GJ264263322101 A.CAPACITOR 16V X M 0.0033UF
C 411 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 412 GJ283115632432 CAPACITOR 100V K 0.056UF
C 414 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 415 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 416 GJ270192240310 E.CAPACITOR 50V VX M 0.22UF
C 417 GJ116229021 A.CAPACITOR 50V B K 470PF
C 418 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 419 GJ116221521 A.CAPACITOR 50V SL J 47PF
C 501 GJ116229121 A.CAPACITOR 50V B K 560PF
C 502 GJ116229121 A.CAPACITOR 50V B K 560PF
C 503 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 504 GJ283111832432 CAPACITOR 100V K 0.018UF
C 505 GJ270111070310 E.CAPACITOR 10V M 100UF
C 506 GJ116228621 A.CAPACITOR 50V B K 220PF
C 507 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 508 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 509 GJ264261822101 A.CAPACITOR 16V X M 0.0018UF
C 510 GJ264263322101 A.CAPACITOR 16V X M 0.0033UF
C 511 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 512 GJ283115632432 CAPACITOR 100V K 0.056UF
C 514 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 515 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 516 GJ270192240310 E.CAPACITOR 50V VX M 0.22UF
C 517 GJ116229021 A.CAPACITOR 50V B K 470PF
C 518 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 519 GJ116221521 A.CAPACITOR 50V SL J 47PF
CN351 GJ340022090108 CONNECTOR 9PIN BLK
CN352 GJ340022160108 CONNECTOR 16PIN BLK
CN353 GJ340022130108 CONNECTOR 13PIN
CN354 GJ158015511 HEADER 3PINS
C9101 GJ116228621 A.CAPACITOR 50V B K 220PF
C9102 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
D 353 1SS133T-77 DIODE GJ871999133
D 354 1SS133T-77 DIODE GJ871999133
FW351 GJ353090220110 CABLE 9PINS
FW352 GJ353160230110 CABLE 16PINS
FW353 GJ353130240110 CABLE 13PINS
IC401 BA3126N IC GJ313030301403
IC402 TA8189N IC GJ875924258
L 351 GJ320060040105 COIL
Q
352 KTC3200GR TRANSISTOR GJ312030131210
Q
354 DTA114YSTP TRANSISTOR GJ872990281
Q
356 2SC2001/LK/-T TRANSISTOR GJ312020012202
Q
357 2SC2001/LK/-T TRANSISTOR GJ312020012202
Q
358 2SA1175TP-F TRANSISTOT GJ872910154
Q
360 DTC144ESTP TRANSISTOR GJ872903003
Q
365 DTC144ESTP TRANSISTOR GJ872903003
Q
366 DTC114YSTP TRANSISTOR GJ872990437
Q
367 2SA934/QR/-T TRANSISTOR GJ872999343
Q
368 2SA934/QR/-T TRANSISTOR GJ872999343
Q
369 KTC3199TPGR TRANSISTOR GJ312030111210
Q
370 2SA934/QR/-T TRANSISTOR GJ872999343
Q
371 KTC3199TPGR TRANSISTOR GJ312030111210
Q
402 2SD2144S/VW/-T TRANSISTOR GJ872992241
Q
403 2SD2144S/VW/-T TRANSISTOR GJ872992241
Q
502 2SD2144S/VW/-T TRANSISTOR GJ872992241
Q
503 2SD2144S/VW/-T TRANSISTOR GJ872992241
R 351 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 352 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 353 GJ250081052103 CARBON RESISTOR 1/6W J 1M
R 354 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 355 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 357 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 358 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 359 GJ250081002103 CARBON RESISTOR 1/6W J 10
R 360 GJ250081002103 CARBON RESISTOR 1/6W J 10
R 361 GJ250084792103 CARBON RESISTOR 1/6W J 4.7
R 362 GJ250085602103 CARBON RESISTOR 1/6W J 56
R 368 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 370 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 371 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 372 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 373 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 374 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 375 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 376 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 378 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 379 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 380 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 381 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 382 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 383 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R 386 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 387 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 388 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 389 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 390 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 391 GJ250081512103 CARBON RESISTOR 1/6W J 150
R 392 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 393 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 394 GJ250081512103 CARBON RESISTOR 1/6W J 150
R 399 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 401 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 402 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 404 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 405 GJ250088222103 CARBON RESISTOR 1/6W J 8.2K
R 406 GJ250088222103 CARBON RESISTOR 1/6W J 8.2K
R 407 GJ250088232103 CARBON RESISTOR 1/6W J 82K
(Cassette amplifier board)
