MX-J200/J206
3-19
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 08
A
R 408 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 409 GJ250081842103 CARBON RESISTOR 1/6W J 180K
R 410 GJ250081222103 CARBON RESISTOR 1/6W J 1.2K
R 411 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 412 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 413 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 414 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 415 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 416 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 417 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 418 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 501 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 502 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 504 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 505 GJ250088222103 CARBON RESISTOR 1/6W J 8.2K
R 506 GJ250088222103 CARBON RESISTOR 1/6W J 8.2K
R 507 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R 508 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 509 GJ250081842103 CARBON RESISTOR 1/6W J 180K
R 510 GJ250081222103 CARBON RESISTOR 1/6W J 1.2K
R 511 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 512 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 513 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 514 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 515 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 516 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 517 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 518 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 09
A
F 951 GJ369000430004 FUSE
A
2A 250V
F 952 GJ369000480008 FUSE
A
1.6A 250V
FT951 GJ153321741 FUSE HOLDER FOR TWE USE
FT952 GJ153321741 FUSE HOLDER FOR TWE USE
FW951 GJ353090190107 CABLE FLAT 9PINS
R 951 GJ251273352201 RESISTOR 1/2W 3.3M 5%
T 951 GJ336660110013 POWER TRANSF.
A
TB901 GJ727000010000 SOLDERING
TB902 GJ727000010000 SOLDERING
(Power transformer board)
(Cassette amplifier board)
To Next Page
