MX-J200/J206
3-20
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 10
A
Item
Parts number Parts name Area
Remarks
A
C 251 NCS21HJ-100X C CAPACITOR
C 252 NCS21HJ-100X C CAPACITOR
C 253 NCB21EK-104X C CAPACITOR
C 254 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 255 NCB21EK-104X C CAPACITOR
C 281 NCB21HK-223X C CAPACITOR
C 291 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 601 NCB21HK-102X C CAPACITOR
C 602 NCB21HK-102X C CAPACITOR
C 603 NCB21HK-223X C CAPACITOR
C 604 NCB21HK-223X C CAPACITOR
C 605 NCS21HJ-271X C CAPACITOR
C 606 NCS21HJ-181X C CAPACITOR
C 607 NCB21HK-222X C CAPACITOR
C 608 NCB21HK-223X C CAPACITOR
C 610 NCB21EK-104X C CAPACITOR
C 611 NCB21EK-104X C CAPACITOR
C 612 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 613 NCS21HJ-101X C CAPACITOR
C 614 NCB21HK-273X C CAPACITOR
C 615 NCB21HK-472X C CAPACITOR
C 616 NCB21HK-103X C CAPACITOR
C 617 NCS21HJ-331X C CAPACITOR
C 621 NCB21EK-104X C CAPACITOR
C 623 NCF21CZ-105X C CAPACITOR
C 624 QER41AM-107 E CAPACITOR 100MF 20% 10V
C 631 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 632 NCF21CZ-105X C CAPACITOR
C 633 NCB21HK-223X C CAPACITOR
C 651 NCS21HJ-120X C CAPACITOR
C 652 NCS21HJ-150X C CAPACITOR
C 653 NCB21EK-104X C CAPACITOR
C 654 NCB21HK-223X C CAPACITOR
C 655 QER41AM-227 E CAPACITOR 220MF 20% 10V
C 656 NCB21EK-104X C CAPACITOR
C 657 NCB21HK-222X C CAPACITOR
C 658 NCB21HK-222X C CAPACITOR
C 661 NCB21EK-104X C CAPACITOR
C 662 QER41AM-107 E CAPACITOR 100MF 20% 10V
C 663 NCB21EK-104X C CAPACITOR
C 664 NCB21HK-223X C CAPACITOR
C 665 NCB21HK-223X C CAPACITOR
C 666 NCS21HJ-471X C CAPACITOR
C 667 NCF21CZ-105X C CAPACITOR
C 668 NCB21HK-473X C CAPACITOR
C 671 NCB21EK-104X C CAPACITOR
C 672 QER41AM-107 E CAPACITOR 100MF 20% 10V
C 801 NCB21HK-822X C CAPACITOR
C 802 NCB21HK-152X C CAPACITOR
C 811 NCS21HJ-221X C CAPACITOR
C 812 NCS21HJ-221X C CAPACITOR
C 813 NCS21HJ-221X C CAPACITOR
C 814 NCS21HJ-221X C CAPACITOR
C 821 NCF21CZ-105X C CAPACITOR
C 822 QER41AM-227 E CAPACITOR 220MF 20% 10V
C 851 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 852 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 855 NCB21EK-104X C CAPACITOR
C 859 NCF21CZ-105X C CAPACITOR
C 860 NCF21CZ-105X C CAPACITOR
CN151 QGF1016F1-15 15FFC CONNECTOR VIDEO CD
CN152 QGA2001F1-12 12P CN RIG VIDEO CD
CN601 QGF1016F1-15 15FFC CONNECTOR TRAVERSE
CN651 QGF1016F1-19 CONNECTOR MAIN
CN652 QGF1016F1-05 CONNECTOR OSD
CN653 QGF1016F1-13 CONNECTOR CD TEXT
CN801 QGA2001C1-06 6P PLUG ASSY TRAVERSE
CN851 QGD2503F1-03 SOCKET DISC DETECTION
CN854 QGB2016K1-07 CONNECTOR TRAY SWITCH
CN855 QGB2012K2-10 CONNECTOR CAM SWITCH
IC251 UPD78055GCA37 IC MICOM
IC601 AN8806SB-W IC RF AMP
IC651 MN35510 IC DSP & DAC
IC801 BA6897FP-W IC PU DRIVE
IC851 TA8409S IC L MOTOR DRIVE
IC852 TA8409S IC R MOTOR DRIVE
L 851 QQL01BK-100Z INDUCTOR VS DE-COUPLE
L 853 QQL01BK-100Z INDUCTOR L MOTOR
L 854 QQL01BK-100Z INDUCTOR R MOTOR
Q
291 2SB1357/EF/-T TRANSISTOR
Q
631 2SA1037AK/RS/-X TRANSISTOR
Q
842 DTA144ES-T TRANSISTOR
R 251 NRSA02J-102X MG RESISTOR
R 252 NRSA02J-102X MG RESISTOR
R 253 NRSA02J-102X MG RESISTOR
R 254 NRSA02J-102X MG RESISTOR
R 255 NRSA02J-102X MG RESISTOR
R 256 NRSA02J-102X MG RESISTOR
R 257 NRSA02J-102X MG RESISTOR
R 258 NRSA02J-102X MG RESISTOR
R 259 NRSA02J-101X MG RESISTOR
R 260 NRSA02J-102X MG RESISTOR
R 261 NRSA02J-102X MG RESISTOR
R 262 NRSA02J-102X MG RESISTOR
R 263 NRSA02J-102X MG RESISTOR
R 264 NRSA02J-102X MG RESISTOR
R 265 NRSA02J-223X MG RESISTOR
R 266 NRSA02J-102X MG RESISTOR
R 267 NRSA02J-102X MG RESISTOR
R 268 NRSA02J-102X MG RESISTOR
R 269 NRSA02J-102X MG RESISTOR
R 274 NRSA02J-102X MG RESISTOR
R 275 NRSA02J-102X MG RESISTOR
R 276 NRSA02J-102X MG RESISTOR
R 277 NRSA02J-102X MG RESISTOR
R 278 NRSA02J-102X MG RESISTOR
R 279 NRSA02J-102X MG RESISTOR
R 281 NRSA02J-102X MG RESISTOR
R 282 NRSA02J-102X MG RESISTOR
R 283 NRSA02J-102X MG RESISTOR
R 284 NRSA02J-102X MG RESISTOR
R 285 NRSA02J-102X MG RESISTOR
R 286 NRSA02J-102X MG RESISTOR
R 287 NRSA02J-102X MG RESISTOR
R 288 NRSA02J-102X MG RESISTOR
R 291 NRSA02J-122X MG RESISTOR
R 292 NRSA02J-103X MG RESISTOR
R 293 NRSA02J-102X MG RESISTOR
R 601 NRSA02J-274X MG RESISTOR
R 602 NRSA02J-154X MG RESISTOR
R 603 NRSA02J-273X MG RESISTOR
R 604 NRSA02J-104X MG RESISTOR
R 605 NRSA02J-154X MG RESISTOR
R 606 NRSA02J-474X MG RESISTOR
R 607 NRSA02J-102X MG RESISTOR
R 611 NRSA02J-113X MG RESISTOR
(CD servo board)
