3-12
Input board
Block No. [0][2]
 R236 FQRL01DJ-271X OMF RESISTOR
 R237 FQRL01DJ-271X OMF RESISTOR
 R238 FQRL01DJ-221X OMF RESISTOR
R240 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
 R246 FQRL01DJ-271X OMF RESISTOR
 R247 FQRL01DJ-271X OMF RESISTOR
 R248 FQRL01DJ-221X OMF RESISTOR
R271 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R601 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
R602 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
R603 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R604 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R605 QRJ146J-122X UNF C RESISTOR 1.2k Ω 1/4W J
 R606 QRJ146J-122X UNF C RESISTOR 1.2k Ω 1/4W J
R607 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R608 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R613 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R614 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R615 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R616 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R617 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R618 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R619 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R620 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R621 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R623 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R650 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
 R652 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
 R654 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
 R656 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R666 QRE141J-333Y C RESISTOR 33k Ω 1/4W J
R667 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R668 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R674 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R675 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R676 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R701 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
 R702 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
R703 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R704 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R705 QRJ146J-821X UNF C RESISTOR 820 Ω 1/4W J
 R706 QRJ146J-821X UNF C RESISTOR 820 Ω 1/4W J
R707 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R708 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R713 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R714 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R715 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R716 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R717 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R718 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R719 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R720 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
R721 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R722 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R723 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R724 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R725 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R726 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R727 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R728 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R729 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R730 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R739 QRE141J-823Y C RESISTOR 82k
Ω 1/4W J
R740 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R741 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R742 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R743 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R744 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R753 QRZ0224-R22 EMIT RESISTOR 0.22
Ω
R754 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R761 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R762 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R766 QRE141J-333Y C RESISTOR 33k Ω 1/4W J
R768 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R769 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
 R774 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R775 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R777 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
R778 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R786 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R787 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R792 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R793 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R1001 QRE141J-331Y C RESISTOR 330
Ω 1/4W J
R1002 QRE141J-331Y C RESISTOR 330
Ω 1/4W J
R1003 QRE141J-331Y C RESISTOR 330 Ω 1/4W J
R1004 QRE141J-331Y C RESISTOR 330 Ω 1/4W J
R1005 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R1006 QRE141J-121Y C RESISTOR 120 Ω 1/4W J
R1007 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R1008 QRE141J-121Y C RESISTOR 120 Ω 1/4W J
R1009 QRE141J-331Y C RESISTOR 330 Ω 1/4W J
R1010 QRE141J-331Y C RESISTOR 330 Ω 1/4W J
R1011 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R1012 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R1013 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R1014 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R1015 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R1016 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
L121 QQLZ035-R39 COIL 0.39uH
L122 QQLZ035-R39 COIL 0.39uH
L123 QQLZ035-R39 COIL 0.39uH
L601 QQLZ035-R39 COIL 0.39uH
L602 QQLZ035-R39 COIL 0.39uH
L701 QQLZ035-R39 COIL 0.39uH
L702 QQLZ035-R39 COIL 0.39uH
CN105 QGA2501F1-03 CONNECTOR W-B (1-3)
CN106 QGD2503F1-03 CONNECTOR (1-3)
CN201 QGB2510J1-09 CONNECTOR B-B (1-9)
CN202 QGB2510J1-09 CONNECTOR B-B (1-9)
CN203 QGB2510J1-14 CONNECTOR B-B (1-14)
CN204 QGB2510K1-12 CONNECTOR B-B (1-12)
CN205 QGB2510J1-12 CONNECTOR B-B (1-12)
CN206 QGB2510K1-11 CONNECTOR B-B (1-11)
CN212 QGB2510K1-09 CONNECTOR B-B (1-9)
CN213 QGB2510K1-14 CONNECTOR B-B (1-14)
CN214 QGB2510J1-12 CONNECTOR B-B (1-12)
CN215 QGB2510K1-12 CONNECTOR B-B (1-12)
CN420 QGF1205C1-12 CONNECTOR FFC/FPC (1-12)
EP201 QNZ0136-001Z EARTH PLATE
FW109 QJK015-082924 WIRE SOCKET
FW207 QUM155-15DGZ4 FLAT WIRE
FW208 QUM157-08DGZ4 FLAT WIRE
FW601 QUM154-10Z4Z4 FLAT WIRE
J81 QNB0171-001 SPK.TERMINAL
J120 QNN0621-001 SPK.TERMINAL
J1010 QNN0434-001 PIN JACK
J1020 QNN0624-001 PIN JACK
RY160 QSK0109-001 RELAY
RY170 QSK0109-001 RELAY
RY240 QSK0109-001 RELAY
RY241 QSK0109-001 RELAY
S1001 QSW0454-001 SW
SP100 GV40205-001A IC HOLDER
 Symbol No. Part No. Part Name Description Local
IC300 HA12237F IC
IC400 NJM4565M-WE IC
IC401 NJM4565M-WE IC
IC410 LB1641 IC
IC414 KTC3200/GL/-T TRANSISTOR
IC420 PQ033EF02SZ REGULATOR IC
IC460 LC75342M-X IC
IC480 JCV8011-X IC
IC500 LC75341M-X IC
IC510 BU9262AFS-X IC
 Symbol No. Part No. Part Name Description Local
