JVC MX-JD8 User Manual

3-17
Front board
Block No. [0][3]
R883 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R884 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R885 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R886 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R887 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R888 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R889 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R890 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R891 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R892 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
UN,U
S,UX
R893 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
UN,U
S,UX
R894 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R895 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R896 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R897 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R898 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R899 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R900 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R901 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R902 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R903 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R904 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R905 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R906 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R907 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R908 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
VR320 QVP0004-203Z TRIM RESISTOR 20k Ω
L317 QQL244K-100Z COIL 10uH K
L320 QQR1118-002 OSC COIL(BIAS)
L812 QQL231K-2R2Y COIL 2.2uH K
L813 QQL231K-2R2Y COIL 2.2uH K
CN11 QGF1036C1-05 CONNECTOR FFC/FPC (1-5)
CN21 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN211 QGB2510K1-09 CONNECTOR B-B (1-9)
CN216 QGB2510J1-11 CONNECTOR B-B (1-11)
CN217 QGD2504C1-05Z CONNECTOR (1-5)
CN218 QGD2504C1-04Z CONNECTOR (1-4)
CN219 QGD2504C1-03Z CONNECTOR (1-3)
CN301 QGA2001C1-07 CONNECTOR W-B (1-7)
CN302 QGA2001C1-03 CONNECTOR W-B (1-3)
CN303 QGF1205C1-13 CONNECTOR FFC/FPC (1-13)
CN410 QGF1205C1-12 CONNECTOR FFC/FPC (1-12)
CN454 QGA2501C1-03 CONNECTOR W-B (1-3) UW
CN522 QGF1036C1-09 CONNECTOR FFC/FPC (1-9)
CN523 QGF1036C1-17 CONNECTOR FFC/FPC (1-17)
CN524 QGF1036C1-15 CONNECTOR FFC/FPC (1-15)
CN531 QGF1036C1-08 CONNECTOR FFC/FPC (1-8)
CN860 QGF1205C1-17 CONNECTOR FFC/FPC (1-17)
CN880 QGF1205C1-12 CONNECTOR FFC/FPC (1-12)
HS420 LE40505-001A HEAT SINK
J454 QNN0420-001 SURROUND JACK
UN,U
S,UX
J812 QNS0089-001 3.5 JACK
J814 GP1FA553TZ OPT TRANSMITTER
PP301 QZW0038-001 WIRE CLAMP
SP300 LV30225-011A SPACER
SP400 LV30225-011A SPACER
SP444 LV30225-011A SPACER
SP810 VYH7653-001 IC HOLDER
TW300 QUB230-06A4A4 WIRE
TW400 QUB230-06A4A4 WIRE
TW444 QUB230-12HPHP S.WIRE
X510 QAX0768-001Z C OSCILLATOR
X801 QAX0724-001Z CRYSTAL 12.000000MHz
 Symbol No. Part No. Part Name Description Local
IC900 SN74HCU04N FL DRIVER
 Symbol No. Part No. Part Name Description Local
IC920 PT6305 FL DRIVER
IC930 GP1UM281XK IR DETECT UNIT 38kHz
IC970 BU9253AS IC
UN,U
S,UX
IC971 RC4580IP IC
UN,U
S,UX
Q926 KRA102M-T DIGI TRANSISTOR
Q933 KRC102M-T DIGI TRANSISTOR
Q934 KRC102M-T DIGI TRANSISTOR
Q935 KRC102M-T DIGI TRANSISTOR
Q936 KRC102M-T DIGI TRANSISTOR
Q937 KRC102M-T DIGI TRANSISTOR
Q938 KRC102M-T DIGI TRANSISTOR
Q980 KRA111M-T DIGI TRANSISTOR
UN,U
S,UX
Q981 KRA111M-T DIGI TRANSISTOR
UN,U
S,UX
Q982 KRA111M-T DIGI TRANSISTOR
UN,U
S,UX
Q987 2SC3576-JVC-T TRANSISTOR
UN,U
S,UX
 Q2010 KTC2026/OY/ TRANSISTOR
Q2011 KTC3199/GL/-T TRANSISTOR
D925 SLA-362LT-T LED
D926 SELU2E10C-P LED
D933 SLA-362LT-T LED
D934 SLA-362LT-T LED
D935 SLA-362LT-T LED
D936 SLA-362LT-T LED
D937 SLA-362LT-T LED
D938 SLA-362LT-T LED
D957 1SS133-T2 DIODE UW
D958 1SS133-T2 DIODE UW
D971 MTZJ5.1B-T2 Z DIODE
UN,U
S,UX
D991 MTZJ2.4B-T2 Z DIODE
UN,U
S,UX
D992 1SS133-T2 DIODE
UN,U
S,UX
 D2010 1N5402M-20 DIODE
 D2011 1N5402M-20 DIODE
 D2012 1N5402M-20 DIODE
 D2013 1N5402M-20 DIODE
D2016 1N4003S-T5 SI DIODE
D2018 MTZJ20B-T2 Z DIODE
D2019 MTZJ18B-T2 Z DIODE
D2020 MTZJ6.8B-T2 Z DIODE
C903 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C904 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C905 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C920 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C921 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C922 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C923 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C924 QEKC1HM-226Z E CAPACITOR 22uF 50V M
C925 QETN1HM-226Z E CAPACITOR 22uF 50V M
C926 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C930 QETN1HM-106Z E CAPACITOR 10uF 50V M
C931 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C957 QCBB1HK-222Y C CAPACITOR 2200pF 50V K UW
C970 QCBB1HK-101Y C CAPACITOR 100pF 50V K
UN,U
S,UX
C971 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
UN,U
S,UX
C972 QETN1CM-107Z E CAPACITOR 100uF 16V M
UN,U
S,UX
C973 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
UN,U
S,UX
C974 QDXB1CM-472Y C CAPACITOR 4700pF 16V M
UN,U
S,UX
C975 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
UN,U
S,UX
C976 QEKC1CM-226Z E CAPACITOR 22uF 16V M
UN,U
S,UX
C977 QEKC1HM-474Z E CAPACITOR 0.47uF 50V M
UN,U
S,UX
 Symbol No. Part No. Part Name Description Local
