DVD servo board
Block No. [0][4]
L998 QQR1183-001Z FERRITE BEADS
CN101 QGD2504C1-03Z CONNECTOR (1-3)
CN119 QGA3901F1-08 CONNECTOR W-B (1-8)
CN250 QGA7901C1-02 CONNECTOR W-B (1-2)
CN810 QGB2024K1-04S CONNECTOR B-B (1-4)
CN820 QGB2024J1-04S CONNECTOR B-B (1-4)
CN870 QGF1205C1-17 CONNECTOR FFC/FPC (1-17)
CN890 QGF1205F1-12 CONNECTOR FFC/FPC (1-12)
FT111 QNG0003-001Z FUSE CLIP
FT112 QNG0003-001Z FUSE CLIP
FT131 QNG0003-001Z FUSE CLIP
FT132 QNG0003-001Z FUSE CLIP
FT151 QNG0003-001Z FUSE CLIP
FT152 QNG0003-001Z FUSE CLIP
FT511 QNG0003-001Z FUSE CLIP
FT512 QNG0003-001Z FUSE CLIP
FT521 QNG0003-001Z FUSE CLIP
FT522 QNG0003-001Z FUSE CLIP
FT531 QNG0003-001Z FUSE CLIP
FT532 QNG0003-001Z FUSE CLIP
FW116 QUM153-29DGZ4 FLAT WIRE
FW241 QUM153-18DGZ4 FLAT WIRE
FW444 QJP001-033600 SINGLE WIRE UW
J970 QNS0236-001 PHONE JACK
UN,U
S,UX
J971 QNS0235-001 PHONE JACK UW
J971 QNS0236-001 PHONE JACK
UN,U
S,UX
J995 QNS0237-001 PHONE JACK
JS920 QSW0857-001 ROTARY SW
 S500 QSW0812-001 VOLTAGE SWITCH
S920 QSW0825-001Z TACT SW
S939 QSW0825-001Z TACT SW
S940 QSW0825-001Z TACT SW
S941 QSW0825-001Z TACT SW
S942 QSW0825-001Z TACT SW
S943 QSW0825-001Z TACT SW
S944 QSW0825-001Z TACT SW
S945 QSW0825-001Z TACT SW
S946 QSW0825-001Z TACT SW
S947 QSW0825-001Z TACT SW
S948 QSW0825-001Z TACT SW
S949 QSW0825-001Z TACT SW
S950 QSW0825-001Z TACT SW
S951 QSW0825-001Z TACT SW
S952 QSW0825-001Z TACT SW
S953 QSW0825-001Z TACT SW
S954 QSW0825-001Z TACT SW
S955 QSW0825-001Z TACT SW
S960 QSW0825-001Z TACT SW
S961 QSW0825-001Z TACT SW
S962 QSW0825-001Z TACT SW
S963 QSW0825-001Z TACT SW
S964 QSW0825-001Z TACT SW
S965 QSW0825-001Z TACT SW
S966 QSW0825-001Z TACT SW
S967 QSW0825-001Z TACT SW
SP920 GV40205-004A IC HOLDER
TW920 QUB220-32HPDM WIRE
TW991 QUB220-18HPDM S.WIRE
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0004AA-H IC
IC302 LM1117MP-ADJ-X IC
IC305 MM1563DF-X IC 3.3V Regulator
IC453 S-80830CNNB-G-W IC
IC505 K4S643232F-TC60 IC
IC505 or K4S643232H-TC60 IC
IC509 AT49BV322AT70TI IC(FLASH)
 Symbol No. Part No. Part Name Description Local
IC509 or MBD32TF70TN IC(MICRO C ROM)
IC512 SN74LVC373APW-X IC(DIGITAL)
IC513 SN74LVC373APW-X IC(DIGITAL)
IC701 AK4384VT-X IC
IC702 AK4384VT-X IC
IC703 AK4384VT-X IC
IC704 CS5342-CZZ-X IC(DIGITAL)
IC705 MM1615AN-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 UN2119-X TRANSISTOR
C101 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C108 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C261 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C262 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C300 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C301 NEA70GM-227X E CAPACITOR 220uF 4V M
C302 NEA70GM-476X E CAPACITOR 47uF 4V M
C303 NEA70GM-476X E CAPACITOR 47uF 4V M
C304 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C305 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C306 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C307 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C308 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C309 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C310 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C311 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C312 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C313 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C314 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C315 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C316 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C317 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C318 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C324 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C325 NDC31HJ-180X C CAPACITOR 18pF 50V J
C326 NDC31HJ-150X C CAPACITOR 15pF 50V J
C328 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C329 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C330 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C331 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C332 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C333 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C334 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C335 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C337 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C338 NCB31HK-562X C CAPACITOR 5600pF 50V K
C339 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C340 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C341 NCF31AZ-105X C CAPACITOR 1uF 10V Z
 Symbol No. Part No. Part Name Description Local
