3-8
Parts List (Exploded view of general assembnly K15R)
! ltem Parts number Parts name Q'ty Description Area ! ltem Parts number Parts name Q'ty Description Area
1 BI109808010101 WINDOW CASS L 1
38 PWB CD 1 251098G01V
2 BI109809010101 WINDOW CASS R 1
39 BI681MXK30000 CD DEC
K
1
3 BI109806020201 BOX CASS L 1
40 BI109836020201 PANEL TOP 1
4 BI109807020201 BOX CASS R 1
41 BI202303010201 BRACKET-PWB-B 1
5 BI109819020201 KNOB VOLUME 1
42 BI2110110080010 PW TRANSFORMER 1
6 BI109823010101 KEY BASS 1
43 PWB PT 1 251153G02V(B)
7 BI109805020201 PANEL CD 1
44 BI109837020401 PANEL SIDE L 1
8 BI109810050101 WINDOW DISPLAY 1
45 PWB MAIN 1 251153G02V(C)
9 BI109830020101 KEY POWER B 1
46 BI109838020401 PANEL SIDE R 1
10 BI109835010101 LOGO JVC 1
47 PWB CONTROL 1 251099G02V(B)
11 BI109834020101 RING VOLUME 1
48 BI109824010201 KEY SOUNCL MODE 1
12 BI109969020201 SPACE
R 2
49 PWB SOUND MODE 1 251099G02V(C)
13 BI301781010101 MIRROR SHEET 1
50 BI301773010101 TAPE DOUBLE SIDE 2
14 BI109804050101 PANEL FRON
T
1
51 BI202267010101 HOLDER-VFD 2
15 BI301388010101 GEAR WHEET DAMP 2
52 PWB VFD 1 251099G02V(D)
16 BI109840010101 LOCKER 2
53 BI202264010101 BRACKET,ADAPTO
R
2
17 BI202408010101 SPRING LOCKER 2
54 PWB TUNNER 1 251151G01V
18 BI109841010101 HLDR LOCKER 2
55 BI202316010201 HEATSINK K10 1
19 BI202266010101 SPRING CASS R 1
56 BI202304010101 HLDR TUNNE
R
1
20 BI301789010101 BUSHING 1
57 BI202377010101 PANEL REAR 1
21 BI202262010401 BOTTOM PLATE 1
58 BI109833020101 KEY CONTROL 1
22 BI103362020102 FOOT RUBBER 4
59 BI109818010101 LES LED 1
23 BI202103010101 HOLDER SENSE
R 1
60 BIRM000604S3 SCREW 16 RH/MS3X8mm
24 G31K300K05S01 KEY CD CHANGE ASSY 1
61 BIRM000601S3 SCREW 4 RH/MS3X6mm
62 BIKT000627 SCREW 2 KH/TS3X12mm
63 BIBT000418 SCREW 31 BH/TS2.6X8mm
64 BIPMW001101S3 SCREW 4 PMW/TS4X8mm
26 BI3101441 DEC
K
1
65 BI202265010101 SPRING CASS L 1
27 BI109832010101 KEY CLOC
K
1
66 BIRT000618B2 SCREW 7 RH/TH3X6mm
28 BI109828010101 KEY DEMO 1
67 BIBT000206 SCREW 2 BH/TS2X8mm
29 BI109829020201 KEY PLAY/STOP 1
68 BIRT000611B3 SCREW 5 RH/TS3X8mm
30 PWB PHONE 1 251153G02V(A)
69 BIBM000603S2 SCREW 2 BH/MS3XL6mm
31 BI109825020201 KEY OPEN/CLOSE 1
70 PWB PHONE HOLDER 2 251099G02V(E)
32 BI202268010101 BRACKET-PWB-A 1
71 BI202337010101 BRACKET FORN
T
1
33 BI109831020101 KEY DUBBING 1
72 BI202348010101 BRACKET CD DEC
K
1
34 BI109826020201 KEY REPEAT 1
73 BI202351010101 BRACKET MB 1
1
1
35 PWB-REPEAT 1 251099G02V(A)
74 BIRT000617B3 SCREW 2 RH/TS3X10mm
36 G31K300K05S02 KEY FUNCTION ASSY 1
75 BI301846010201 PC SHEET 1
76 BIRT000621B3 SCREW 3 RH/TS3X8mm
! 77 BI402891 FUSE 1.6A 250V F952
! 78 BI402821 FUSE 1A 250V
! 79 BI1401001 AC CORD 1
CMAT6Z219A
