JVC MX-K30R User Manual

 Electrical parts list (K10/30/15 FRONT DISPLY UICOM SELECTION )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
111 O R754 NRSA63J-222X MG RESISTOR 2.2K
112 O R755 NRSA63J-222X MG RESISTOR 2.2K
113 O R756 NRSA63J-222X MG RESISTOR 2.2K
114 O R757 NRSA63J-102X MG RESISTOR 1K
115 O R758 NRSA63J-222X MG RESISTOR 2.2K
116 O R759 NRSA63J-2R2X MG RESISTOR 2.2
117 O R760 NRSA63J-2R2X MG RESISTOR 2.2
118 O R761 NRSA63J-473X MG RESISTOR 47K
119 O R768 NRSA63J-104X MG RESISTOR 100K
120 O R769 NRSA63J-102X MG RESISTOR 1K
121 O R770 NRSA63J-222X MG RESISTOR 2.2K
122 O R771 NRSA63J-221X MG RESISTOR 220
123 O R772 NRSA63J-222X MG RESISTOR 2.2K
124 O R773 NRSA63J-222X MG RESISTOR 2.2K
125 O R774 NRSA63J-182X MG RESISTOR 1.8K
126 O R775 NRSA63J-102X MG RESISTOR 1K
127 O R776 NRSA63J-103X MG RESISTOR 10K
128 O R777 NRSA63J-473X MG RESISTOR 47K
129 O R778 NRSA63J-102X MG RESISTOR 1K
130 O R779 NRSA63J-103X MG RESISTOR 10K
131 O R780 NRSA63J-222X MG RESISTOR 2.2K
132 O R781 NRSA63J-102X MG RESISTOR 1K
133 O R782 NRSA63J-222X MG RESISTOR 2.2K
134 O R783 NRSA63J-473X MG RESISTOR 47K
135 O R784 NRSA63J-222X MG RESISTOR 2.2K
136 O R785 NRSA63J-222X MG RESISTOR 2.2K
137 O R786 NRSA63J-103X MG RESISTOR 10K
138 O R787 NRSA63J-103X MG RESISTOR 10K
139 O R788 NRSA63J-102X MG RESISTOR 1K
140 O R789 NRSA63J-222X MG RESISTOR 2.2K
141 O R790 NRSA63J-102X MG RESISTOR 1K
142 O R791 NRSA63J-101X MG RESISTOR 100
143 O R792 NRSA63J-331X MG RESISTOR 330
144 O R1001 NRSA63J-681X MG RESISTOR 680
145 O R1002 NRSA63J-681X MG RESISTOR 680
146 O R1003 NRSA63J-821X MG RESISTOR 820
147 O R1004 NRSA63J-102X MG RESISTOR 1K
148 O R1005 NRSA63J-152X MG RESISTOR 1.5K
149 O R1006 NRSA63J-183X MG RESISTOR 18K
150 O R1007 NRSA63J-822X MG RESISTOR 8.2K
151 O R1008 NRSA63J-681X MG RESISTOR 680
152 O R1009 NRSA63J-681X MG RESISTOR 680
153 O R1010 NRSA63J-681X MG RESISTOR 680
154 O R1011 NRSA63J-821X MG RESISTOR 820
155 O R1012 NRSA63J-102X MG RESISTOR 1K
156 O R1013 NRSA63J-152X MG RESISTOR 1.5K
157 O R1014 NRSA63J-222X MG RESISTOR 2.2K
158 O R1015 NRSA63J-272X MG RESISTOR 2.7K
159 O R1016 NRSA63J-183X MG RESISTOR 18K
160 O R1017 NRSA63J-681X MG RESISTOR 680
161 O R1018 NRSA63J-681X MG RESISTOR 680
162 O R1019 NRSA63J-821X MG RESISTOR 820
163 O R1020 NRSA63J-102X MG RESISTOR 1K
164 O R1021 NRSA63J-152X MG RESISTOR 1.5K
165 O R1022 NRSA63J-222X MG RESISTOR 2.2K
3-13

JVC MX-K30R Specifications

General

Brand	JVC
Model	MX-K30R
Category	Speaker System
Language	English
