3-1
PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
CD changer mechanism assembly and parts list (Block No.MA)
Cassette mechanism assembly and parts list (Block No.MP)
Electrical parts list (Block No.01~04)
Packing materials and accessories parts list (Block No.M3)
- Note-
Parts number of normal capacitors and normal resistors doesn't listed on the parts list
[ MX-KB4 ]
3- 2
3- 5
3- 7
3- 9
3-12
Area suffix
J ----------------------------- U.S.A.
C -------------------------- Canada
MB196
