RX-E112RSL/RX-E111RSL
RX-E112RSL/RX-E111RSL
3-4
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 LV10482-005A
FRONT PANEL
1
RX-E112RSL
LV10482-004A
FRONT PANEL
1
RX-E111RSL
2 VJD5429-002SS
JVC MARK
1
3 QYSBSF2608Z
T.SCREW
1
FOR PHONE PWB
4 LV20958-010A
LENS
1
RX-E112RSL
LV20958-009A
LENS
1
RX-E111RSL
5 LV20991-001A
POWER BUTTON
1
6 LV42096-001A
INDICATOR
1
7 LV32517-002A
CONTROL BUTTON
1
8 LV20959-005A
SOURCE BUTTON
1
9 LV32519-001A
SOURCE INDICATO
2
10 LV32552-005A
INDI.ESCUTCHEON
1
11 LV20992-001A
VOLUME BUTTON
1
12 QYSBSF2608Z
T.SCREW
2
BIND TO BRAIZER
13 LV42195-001A
FL SCREEN
1
TO FRONT PANEL
14 QYSBSF2608Z
T.SCREW
8
BIND TO BRAIZER
15 QUQ412-0946CJ
FFC WIRE
1
16 QUQ412-2138CJ
FFC WIRE
1
17 QUQ412-1413CJ
FFC WIRE
1
18 QYSBSG3006Z
T.SCREW
4
F.PANEL+F.BKT(BOTT.)
19 QYSBSG3006Z
T.SCREW
3
F.PANEL+F.BKT(UP)
20 LV10019-004A
CHASSIS BASE
1
21 LV10483-002A
FRONT BRACKET
1
22 QYSBSG3006Z
T.SCREW
5
C.BASE+F.BKT
23 E68587-223SM
CB BKT
3
24 QYSBSG3006Z
T.SCREW
3
CB BKT+C.BASE
25 E47227-020
FOOT
4
26 QYSBSG3008Z
T.SCREW
4
FOOT ASS'Y+C.BASE
27 LV21236-001A
HEAT SINK
1
28 QYSBSG3012E
SCREW
10
29 LV32433-001A
H.S BRACKET(R)
1
30 LV32434-001A
H.S BRACKET(L)
1
31 QYSBSG3008Z
T.SCREW
4
H.SINK BKT+H.SINK
32 QYSBSG3006Z
T.SCREW
2
H.SINK BKT+F.BKT
33 QYSBSG3006Z
T.SCREW
2
AMP M.C.B+H.SINK
34 QYSBSG3006Z
T.SCREW
2
H.SINK BKT+C.BASE
35 QYSBSG3006Z
T.SCREW
3
A.M.C.B+C.B.&CB BKT
36 LV42098-001A
C.B BKT
1
37 QYSBSG3006Z
T.SCREW
1
C.B.BKT+C.BASE
38 QYSBSG3006Z
T.SCREW
3
T.C.B+C.BASE&F.BKT
39 QYSBSG3006Z
T.SCREW
1
P.CORD C.B+C.BASE
40 QQT0364-001
POWER TRANSF
A
1
T 201
41 QYSDSTL4008E
SPECIAL SCREW
4
P.TRANS
42 LV21232-005A
REAR PANEL
B,E,EN
1
RX-E111RSL
LV21232-006A
REAR PANEL
EV
1
RX-E111RSL
LV21232-007A
REAR PANEL
B,E,EN
1
RX-E112RSL
LV21232-008A
REAR PANEL
EV
1
RX-E112RSL
43 QYSBSGY3008M
SPECIAL SCREW
4
R.PANEL+C.BASE
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
44 QYSBSGY3008M
SPECIAL SCREW
1
45 QYSBSGY3008M
SPECIAL SCREW
2
TUNER
46 QUQ412-2306CJ
FFC WIRE
1
I.M.C.B TO SCAR
47 QYSBSGY3008M
SPECIAL SCREW
4
SCART 2
48 QYSBSGY3008M
SPECIAL SCREW
1
SUB WOOFER
49 QYSBSGY3008M
SPECIAL SCREW
1
TAPE
50 QYSBSGY3008M
SPECIAL SCREW
4
SCART
51 QYSBSGY3008M
SPECIAL SCREW
2
DIGITAL
52 QYSBSGY3008M
SPECIAL SCREW
2
F.SPK TERM.+R.P
53 QYSBSGY3008M
SPECIAL SCREW
2
R.SPK TERM.+R.P
54 QYSBSG3006Z
T.SCREW
3
INPUT M.C.B+C.B
55 QMPK250-205-JV
POWER CORD
E,EN,EV
A
1
QMPN100-200-JD
POWER CORD
B
A
1
56 QZW0033-001
STRAIN RELIEF
A
1
57 LV20962-004A/S/
TOP COVER
1
58 QYSBSGY3008M
SPECIAL SCREW
3
59 E406308-004
SPECIAL SCREW
4
60 QMF51W2-1R6-J8
FUSE
A
1
F 201
61 QMF51W2-2R0-J8
FUSE
A
2
F 202 F 203
62 QMF51E2-R10-J1
FUSE
A
1
F 204
63 E307572-001
FASTENER
1
TIE POWER CORD
64 E409396-003
CAUTION LABEL
1
65 QYSBSG3008E
T.SCREW
1
66 LV30225-0C1A
FELT SPACER
2
FS400 FS401
67 QYSBSG3008E
T.SCREW
1
68 QYSBSG3008E
T.SCREW
1
69 QYSBSG3008E
T.SCREW
2
70 QYSBSG3008E
T.SCREW
1
71 QYSBSG3008E
T.SCREW
1
72 QYSBSG3006Z
T.SCREW
1
PHONE PWB
