RX-E112RSL/RX-E111RSL

Electrical parts list (Power amp board)

Block No. 01

Item

Parts number Parts name Ar

Remarks

C 201 QFLC2AJ-104Z M CAPACITOR .10MF 5% 100V

C 202 QFLC2AJ-104Z M CAPACITOR .10MF 5% 100V

C 203 QFLC2AJ-104Z M CAPACITOR .10MF 5% 100V

C 204 QETM1VM-228 E.CAPACITOR 2200MF 20% 35V

C 205 QETM1VM-108 E.CAPACITOR 1000MF 20% 35V

C 206 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V

C 207 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V

C 208 QFLC2AJ-472Z M CAPACITOR 4700PF 5% 100V

C 209 QETN1EM-477Z E CAPACITOR 470MF 20% 25V

C 210 QCZ9104-472 C CAPACITOR

4700PF

C 212 QETN1CM-477Z E CAPACITOR 470MF 20% 16V

C 213 QETN0JM-228Z E CAPACITOR 2200MF 20% 6.3V

C 218 QEKC1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 221 QETN1EM-107Z E CAPACITOR 100MF 20% 25V

C 225 QDVB1EZ-223Y C CAPACITOR 0.022MF

C 301 QTE1H28-475Z E CAPACITOR 4.7MF 20% 500V

C 302 QTE1H28-475Z E CAPACITOR

C 303 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V

C 304 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V

C 305 QCS31HJ-271Z C CAPACITOR 270PF 5% 50V

C 306 QCS31HJ-271Z C CAPACITOR 270PF 5% 50V

C 307 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V

C 308 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V

C 309 QETN1CM-227Z E CAPACITOR 220MF 20% 16V

C 310 QETN1CM-227Z E CAPACITOR 220MF 20% 16V

C 311 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V

C 312 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V

C 313 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V

C 314 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V

C 315 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V

C 316 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V

C 317 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 318 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 319 QETN1JM-107Z E CAPACITOR 100MF 20% 63V

C 320 QETN1JM-107Z E CAPACITOR 100MF 20% 63V

C 321 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 322 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 323 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 324 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 801 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 802 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 803 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V

C 804 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V

C 805 QCS31HJ-331Z C CAPACITOR 330PF 5% 50V

C 806 QCS31HJ-331Z C CAPACITOR 330PF 5% 50V

C 807 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V

C 808 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V

C 809 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 810 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 811 QCS31HJ-8R0Z C CAPACITOR 8.0PF 5% 50V

C 812 QCS31HJ-8R0Z C CAPACITOR 8.0PF 5% 50V

C 813 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V

C 814 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V

C 815 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V

C 816 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V

C 817 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 818 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 819 QETN1JM-476Z E CAPACITOR 47MF 20% 63V

C 820 QETN1JM-476Z E CAPACITOR 47MF 20% 63V

C 821 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 822 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 823 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 824 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 825 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V

C 826 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V

C 827 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V

C 828 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V

C 829 QETN1HM-476Z E CAPACITOR 47MF 20% 50V

C 830 QETN1HM-476Z E CAPACITOR 47MF 20% 50V

C 901 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 903 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V

C 905 QCS31HJ-271Z C CAPACITOR 270PF 5% 50V

C 907 QCB31HK-152Z C CAPACITOR 1500PF 10% 50V

C 909 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 911 QCS31HJ-100Z C CAPACITOR 10PF 5% 50V

C 913 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V

C 915 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V

C 917 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 919 QETN1JM-476Z E CAPACITOR 47MF 20% 63V

C 921 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 923 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 925 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V

C 927 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V

C 929 QETN1HM-476Z E CAPACITOR 47MF 20% 50V

CN201 QGD2501C1-05Z SOCKET I.M

CN204 QGF1205C1-14 CONNECTOR

CN207 WJK0037-001A E-SI C WIRE C-B

CN209 QGD2501C1-03Z SOCKET

CN212 QJK017-031301 SIN CR C-B WIRE

CN217 QGA7901C1-02 CONNECTOR

CN701 QGB2510K1-10 CONNECTOR

CN702 QGB2510K1-10 CONNECTOR

CN703 QGB2510K1-09 CONNECTOR

CN704 QGB2510K1-09 CONNECTOR

CN705 QGB2510K1-09 CONNECTOR

CN707 QGD2501C1-04Z SOCKET

D 201 10E2-FD DIODE

D 202 11ES2-T4 DIODE I.M

D 203 10E2-FD DIODE

D 204 11ES2-T4 DIODE I.M

D 206 11ES2-T4 DIODE I.M

D 207 11ES2-T4 DIODE I.M

D 208 11ES2-T4 DIODE I.M

D 209 11ES2-T4 DIODE I.M

D 210 1SS133-T2 SI DIODE IM

D 211 MTZJ6.2C-T2 Z DIODE I/M

D 212 11ES2-T4 DIODE I.M

D 217 MTZJ6.2C-T2 Z DIODE I/M

D 219 11ES2-T4 DIODE I.M

D 220 11ES2-T4 DIODE I.M

D 221 MTZJ6.2C-T2 Z DIODE I/M

D 222 1SS133-T2 SI DIODE IM

D 301 1SS133-T2 SI DIODE IM

D 302 1SS133-T2 SI DIODE IM

D 303 SLR-342MC-T LED

D 304 SLR-342MC-T LED

D 305 1SS133-T2 SI DIODE IM

D 306 1SS133-T2 SI DIODE IM

D 307 1SS133-T2 SI DIODE IM

D 308 1SS133-T2 SI DIODE IM

D 309 1SS133-T2 SI DIODE IM

D 310 1SS133-T2 SI DIODE IM

D 801 1SS133-T2 SI DIODE IM

D 802 1SS133-T2 SI DIODE IM

D 805 1SS133-T2 SI DIODE IM

D 806 1SS133-T2 SI DIODE IM
