RX-E112RSL/RX-E111RSL
Item
Parts number Parts name Ar
e
a
Remarks
A
L 743 QQLZ005-R45 INDUCTOR
L 744 QQLZ005-R45 INDUCTOR
L 745 QQLZ005-R45 INDUCTOR
Q
401 KTC3199/GL/-T TRANSISTOR
Q
402 KTC3199/GL/-T TRANSISTOR
Q
403 KTC3199/GL/-T TRANSISTOR
Q
404 KTC3199/GL/-T TRANSISTOR
Q
405 KTC3199/GL/-T TRANSISTOR
Q
406 KTC3199/GL/-T TRANSISTOR
Q
407 DTC114EKA-X TRANSISTOR
Q
702 KTC3200/GL/-T TRANSISTOR
Q
703 KTA1268/GL/-T TRANSISTOR
Q
704 KTC3199/GL/-T TRANSISTOR
Q
705 2SD2395/EF/ TRANSISTOR
Q
706 KTC3200/GL/-T TRANSISTOR
Q
708 KRC109M-T D.TR.I.M.
Q
710 KRC109M-T D.TR.I.M.
Q
711 KRC109M-T D.TR.I.M.
Q
712 KRC109M-T D.TR.I.M.
Q
713 KRC109M-T D.TR.I.M.
Q
714 KRC109M-T D.TR.I.M.
Q
715 KRC109M-T D.TR.I.M.
Q
716 KTA1046/Y/ TRANSISTOR
R 351 QRJ125J-100 UNF C RESISTOR
A
10 5% 1/2W
R 352 QRJ125J-100 UNF C RESISTOR
A
10 5% 1/2W
R 353 QRL027J-100 UNF OMF RESISTO
A
10 5% 1/2W
R 354 QRL027J-100 UNF OMF RESISTO
A
10 5% 1/2W
R 400 NRSA63J-103X MG RESISTOR
R 401 NRSA63J-223X MG RESISTOR
R 402 NRSA63J-473X MG RESISTOR
R 403 NRSA63J-683X MG RESISTOR
R 404 NRSA63J-473X MG RESISTOR
R 405 NRSA63J-153X MG RESISTOR
R 406 NRSA63J-273X MG RESISTOR
R 407 NRSA63J-103X MG RESISTOR
R 408 NRSA63J-103X MG RESISTOR
R 409 NRSA63J-223X MG RESISTOR
R 410 NRSA63J-473X MG RESISTOR
R 411 NRSA63J-683X MG RESISTOR
R 412 NRSA63J-473X MG RESISTOR
R 413 NRSA63J-153X MG RESISTOR
R 414 NRSA63J-273X MG RESISTOR
R 415 NRSA63J-103X MG RESISTOR
R 416 NRSA63J-103X MG RESISTOR
R 417 NRSA63J-223X MG RESISTOR
R 418 NRSA63J-473X MG RESISTOR
R 419 NRSA63J-683X MG RESISTOR
R 420 NRSA63J-473X MG RESISTOR
R 421 NRSA63J-153X MG RESISTOR
R 422 NRSA63J-273X MG RESISTOR
R 423 NRSA63J-103X MG RESISTOR
R 424 NRSA63J-103X MG RESISTOR
R 425 NRSA63J-103X MG RESISTOR
R 426 NRSA63J-223X MG RESISTOR
R 427 NRSA63J-472X MG RESISTOR
R 428 NRSA63J-221X MG RESISTOR
R 429 NRSA63J-103X MG RESISTOR
R 430 NRSA63J-102X MG RESISTOR
R 431 NRSA63J-102X MG RESISTOR
R 432 NRSA63J-122X MG RESISTOR
R 433 NRSA63J-152X MG RESISTOR
R 434 NRSA63J-222X MG RESISTOR
R 435 NRSA63J-272X MG RESISTOR
R 436 NRSA63J-103X MG RESISTOR
R 437 NRSA63J-102X MG RESISTOR
R 438 NRSA63J-102X MG RESISTOR
R 439 NRSA63J-122X MG RESISTOR
R 440 NRSA63J-152X MG RESISTOR
R 441 NRSA63J-222X MG RESISTOR
R 442 NRSA63J-272X MG RESISTOR
R 443 NRSA63J-392X MG RESISTOR
R 444 NRSA63J-103X MG RESISTOR
R 445 NRSA63J-102X MG RESISTOR
R 446 NRSA63J-102X MG RESISTOR
R 447 NRSA63J-122X MG RESISTOR
R 448 NRSA63J-152X MG RESISTOR
R 449 NRSA63J-222X MG RESISTOR
R 450 NRSA63J-272X MG RESISTOR
R 451 NRSA63J-392X MG RESISTOR
R 455 NRSA63J-103X MG RESISTOR
R 456 NRSA63J-103X MG RESISTOR
R 457 NRSA63J-102X MG RESISTOR
R 458 NRSA63J-102X MG RESISTOR
R 459 NRSA63J-122X MG RESISTOR
R 464 NRSA63J-221X MG RESISTOR
R 465 NRSA63J-221X MG RESISTOR
R 466 NRSA63J-221X MG RESISTOR
R 467 NRSA63J-221X MG RESISTOR
R 468 NRSA63J-221X MG RESISTOR
R 469 NRSA63J-221X MG RESISTOR
R 470 NRSA63J-221X MG RESISTOR
R 471 NRSA63J-221X MG RESISTOR
R 472 NRSA63J-221X MG RESISTOR
R 473 NRSA63J-221X MG RESISTOR
R 474 NRSA63J-221X MG RESISTOR
R 475 NRSA63J-221X MG RESISTOR
R 476 NRSA63J-221X MG RESISTOR
R 477 NRSA63J-221X MG RESISTOR
R 478 NRSA63J-221X MG RESISTOR
R 479 NRSA63J-221X MG RESISTOR
R 480 NRSA63J-221X MG RESISTOR
R 481 NRSA63J-103X MG RESISTOR
R 482 NRSA63J-221X MG RESISTOR
R 488 NRSA63J-103X MG RESISTOR
R 489 NRSA63J-103X MG RESISTOR
R 490 NRSA63J-103X MG RESISTOR
R 491 NRSA63J-221X MG RESISTOR
R 492 NRSA63J-392X MG RESISTOR
R 493 NRSA63J-103X MG RESISTOR
R 494 NRSA63J-103X MG RESISTOR
R 495 NRSA63J-103X MG RESISTOR
R 496 NRSA63J-103X MG RESISTOR
R 497 NRSA63J-103X MG RESISTOR
R 498 NRSA63J-103X MG RESISTOR
R 499 NRSA63J-103X MG RESISTOR
R 701 QRL027J-332 UNF OMF RESISTO
A
3.3K 5% 1/2W
R 704 NRSA63J-104X MG RESISTOR
R 705 NRSA63J-104X MG RESISTOR
R 706 NRSA63J-823X MG RESISTOR
R 707 NRSA63J-104X MG RESISTOR
R 708 NRSA63J-823X MG RESISTOR
R 709 NRSA63J-103X MG RESISTOR
R 710 NRSA63J-103X MG RESISTOR
R 711 NRSA63J-104X MG RESISTOR
R 712 NRSA63J-104X MG RESISTOR
R 713 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
Electrical parts list (Main & System control board)
Block No. 02
Item
Parts number Parts name Ar
e
a
Remarks
A
