3-10
RX-E112RSL/RX-E111RSL
Item
Parts number Parts name Ar
e
a
Remarks
A
R 714 QRK126J-222X UNF C.RES I/M
A
2.2K 5% 1/2W
R 718 NRSA63J-103X MG RESISTOR
R 719 NRSA63J-473X MG RESISTOR
R 720 QRJ146J-392X UNF C RESISTOR
A
3.9K 5% 1/4W
R 721 NRSA63J-472X MG RESISTOR
R 722 NRSA63J-223X MG RESISTOR
R 723 NRSA63J-153X MG RESISTOR
R 725 NRSA63J-472X MG RESISTOR
R 726 NRSA63J-472X MG RESISTOR
R 727 NRSA63J-472X MG RESISTOR
R 728 NRSA63J-472X MG RESISTOR
R 729 NRSA63J-223X MG RESISTOR
R 730 NRSA63J-153X MG RESISTOR
R 731 NRSA63J-223X MG RESISTOR
R 732 NRSA63J-153X MG RESISTOR
R 735 QRJ146J-120X UNF C RESISTOR
A
12 5% 1/4W
R 736 QRZ9005-100X F RESISTOR
A
10 1/4W
R 737 QRJ146J-562X UNF C RESISTOR
A
5.6K 5% 1/4W
R 741 QRJ146J-120X UNF C RESISTOR
A
12 5% 1/4W
R 742 QRJ146J-120X UNF C RESISTOR
A
12 5% 1/4W
R 743 QRJ146J-120X UNF C RESISTOR
A
12 5% 1/4W
R 745 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
R 746 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
R 747 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
R 748 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
R 749 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
RY701 QSK0082-001 RELAY
A
RY741 QSK0109-001 RELAY
A
RY742 QSK0109-001 RELAY
A
RY743 QSK0109-001 RELAY
A
R1422 NRSA63J-104X MG RESISTOR
S 401 QSW0683-001Z PUSH SWITCH SURROUND
S 402 QSW0683-001Z PUSH SWITCH SURR MODE
S 403 QSW0683-001Z PUSH SWITCH INPUT MODE
S 404 QSW0683-001Z PUSH SWITCH DVD
S 405 QSW0683-001Z PUSH SWITCH STB
S 406 QSW0683-001Z PUSH SWITCH UP
S 407 QSW0683-001Z PUSH SWITCH LEFT
S 408 QSW0683-001Z PUSH SWITCH VOL.DOWN
S 409 QSW0683-001Z PUSH SWITCH ADJUST
S 410 QSW0683-001Z PUSH SWITCH SETTING
S 411 QSW0683-001Z PUSH SWITCH VCR
S 412 QSW0683-001Z PUSH SWITCH TV
S 413 QSW0683-001Z PUSH SWITCH DOWN
S 414 QSW0683-001Z PUSH SWITCH RIGHT
S 415 QSW0683-001Z PUSH SWITCH VOL.UP
S 416 QSW0683-001Z PUSH SWITCH MEMORY
S 417 QSW0683-001Z PUSH SWITCH TAPE
S 418 QSW0683-001Z PUSH SWITCH FM/AM
S 421 QSW0683-001Z PUSH SWITCH POWER
S 422 QSW0683-001Z PUSH SWITCH AMP/SWITCH
ST741 QNB0139-001 SPK TERMINAL FRONT
ST742 QNB0140-001 SPK TERMINAL CNT/SR
X 401 QAX0246-001Z C RESONATOR
Electrical parts list (Main & System control board)
Block No. 02
