3-11

RX-E112RSL/RX-E111RSL

Item

Parts number Parts name Ar

Remarks

C 501 NCS31HJ-331X C.CAPA. C.M

C 502 NCS31HJ-331X C.CAPA. C.M

C 503 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 504 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 505 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 506 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 507 NCS31HJ-331X C.CAPA. C.M

C 508 NCS31HJ-331X C.CAPA. C.M

C 509 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 510 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 511 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 512 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 513 NCS31HJ-331X C.CAPA. C.M

C 514 NCS31HJ-331X C.CAPA. C.M

C 515 NCS31HJ-221X C.CAPA. C.M

C 516 NCS31HJ-221X C.CAPA. C.M

C 517 NCS31HJ-331X C.CAPA. C.M

C 518 NCS31HJ-331X C.CAPA. C.M

C 519 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 520 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 521 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 522 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 523 QFLC1HJ-683Z M CAPACITOR .068MF 5% 50V

C 524 QFLC1HJ-683Z M CAPACITOR .068MF 5% 50V

C 525 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V

C 526 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V

C 527 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V

C 528 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V

C 529 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 530 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 531 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C 532 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C 533 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C 534 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C 535 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V

C 536 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V

C 537 QEKC1AM-476Z E CAPACITOR 47MF 20% 10V

C 538 NCB31HK-561X C CAPACITOR

C 541 QTE1H28-106Z E CAPACITOR

C 542 QTE1H28-106Z E CAPACITOR

C 544 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 545 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 546 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 547 QCBB1HK-681Y C CAPACITOR 680PF 10% 50V

C 548 QCBB1HK-681Y C CAPACITOR 680PF 10% 50V

C 549 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 550 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 551 QFLC1HJ-562Z M CAPACITOR 5600PF 5% 50V

C 552 QFLC1HJ-562Z M CAPACITOR 5600PF 5% 50V

C 553 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 554 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V

C 555 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V

C 556 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V

C 557 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 558 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 559 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 560 QETN1EM-107Z E CAPACITOR 100MF 20% 25V

C 561 QETN1EM-107Z E CAPACITOR 100MF 20% 25V

C 562 QETN1EM-107Z E CAPACITOR 100MF 20% 25V

C 563 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C 564 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%

C 565 QETN1EM-107Z E CAPACITOR 100MF 20% 25V

C 566 QETN1EM-107Z E CAPACITOR 100MF 20% 25V

C 577 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 581 QEKC1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 591 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C 592 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C 593 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 594 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 595 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 596 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

CL501 QZW0038-001 WIRE CLAMP

CL502 QZW0038-001 WIRE CLAMP

CN224 QGD2501C1-03Z SOCKET

CN225 QGD2501C1-03Z SOCKET

CN411 QGF1205C1-21 CONNECTOR

CN412 QGF1205F1-09 CONNECTOR

CN501 QGB2510J1-20 CONNECTOR

CN502 QGF1205C1-23 CONNECTOR

CN503 QGB2510J1-12 CONNECTOR

CN504 QGB2510J1-04 CONNECTOR

CN505 QJP001-031401 SHI CR C-B WIRE

CN506 QJP002-021401 SHI CR C-B WIRE

CN507 QJP001-030801 SHI CR C-B WIRE

CN511 QGB2510K1-20 B TO B CONNE

CN512 QGF1205F1-23 CONNECTOR

CN601 QGB2510J1-20 CONNECTOR

C1501 NCS31HJ-331X C.CAPA. C.M

C1502 NCS31HJ-331X C.CAPA. C.M

C1505 NCS31HJ-331X C.CAPA. C.M

C1506 NCS31HJ-331X C.CAPA. C.M

C1507 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C1508 NCS31HJ-470X C.CAPA. C.M

C1509 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C1510 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C1511 NCS31HJ-331X C.CAPA. C.M

C1512 NCS31HJ-331X C.CAPA. C.M

C1515 NCS31HJ-331X C.CAPA. C.M

C1516 NCS31HJ-331X C.CAPA. C.M

C1517 NCS31HJ-470X C.CAPA. C.M

C1518 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C1519 NCS31HJ-470X C.CAPA. C.M

C1520 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C1521 NCS31HJ-470X C.CAPA. C.M

C1522 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C1523 NCS31HJ-470X C.CAPA. C.M

C1524 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C1528 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V

C1529 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C1536 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C1538 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C1539 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V

C1540 NCS31HJ-470X C.CAPA. C.M

C1543 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C1546 NCF31CZ-104X C CAPACITOR

C1547 NCF31CZ-104X C CAPACITOR

D 503 MTZJ7.5C-T2 ZENER DIODE

D 504 MTZJ7.5C-T2 ZENER DIODE

D 505 MTZJ15C-T2 Z DIODE

D 506 MTZJ15C-T2 Z DIODE

D 507 MTZJ5.6C-T2 ZENER DIODE

D 508 MTZJ5.6C-T2 ZENER DIODE

D 509 1SS355-X DIODE C.M

D 511 MTZJ13C-T2 ZENER DIODE

D 512 MTZJ13C-T2 ZENER DIODE

D 513 MTZJ13C-T2 ZENER DIODE

Electrical parts list (Audio signal input board)

Block No. 03

Item

Parts number Parts name Ar

Remarks
