3-12
RX-E112RSL/RX-E111RSL
Item
Parts number Parts name Ar
e
a
Remarks
A
D 514 MTZJ13C-T2 ZENER DIODE
D 515 MTZJ13C-T2 ZENER DIODE
D 516 MTZJ13C-T2 ZENER DIODE
D 517 MTZJ13C-T2 ZENER DIODE
D 518 MTZJ13C-T2 ZENER DIODE
D 519 MTZJ10C-T2 Z.DIODE I.M
D 520 MTZJ13C-T2 ZENER DIODE
D1501 MTZJ13C-T2 ZENER DIODE
D1503 MTZJ13C-T2 ZENER DIODE
D1504 MTZJ13C-T2 ZENER DIODE
D1505 MTZJ13C-T2 ZENER DIODE
EP502 QNZ0136-001Z EARTH PLATE
FL501 QQR0590-001 FILTER
FL502 QQR0590-001 FILTER
HS512 E70306-001 HEAT SINK
HS513 E70306-001 HEAT SINK
HS514 E70306-001 HEAT SINK
HS515 E70306-001 HEAT SINK
HS520 E70306-001 HEAT SINK
HS526 E70306-001 HEAT SINK
IC501 M61501FP IC
IC503 BA15218F-XE IC
IC511 NJM2246M-X IC
IC512 NJM2246M-X IC
IC513 NJM2246M-X IC
IC514 BA7625 IC
IC515 TC74HC4053AF-X I.C C.M
J 501 QNZ0516-001 RGB CONNECTOR DVD
J 502 QNZ0516-001 RGB CONNECTOR STB
J 503 QNN0163-001 PIN JACK
J 504 QNN0060-001 PIN JACK SUBWOOFER OUT
J1501 QNZ0516-001 RGB CONNECTOR VCR
J1502 QNZ0516-001 RGB CONNECTOR TV
Q
501 2SC3576-JVC-T TRANSISTOR I/M
Q
502 2SC3576-JVC-T TRANSISTOR I/M
Q
503 2SC3576-JVC-T TRANSISTOR I/M
Q
505 2SC3576-JVC-T TRANSISTOR I/M
Q
506 2SC3576-JVC-T TRANSISTOR I/M
Q
507 2SC3576-JVC-T TRANSISTOR I/M
Q
508 2SC3576-JVC-T TRANSISTOR I/M
Q
509 DTA114YKA-X TRANSISTOR
Q
510 KTA1271/OY/-T TRANSISTOR
A
Q
511 KTC3203/OY/-T TRANSISTOR
A
Q
512 KTA1046/Y/ TRANSISTOR
A
Q
513 2SD2395/EF/ TRANSISTOR
A
Q
514 2SD2395/EF/ TRANSISTOR
A
Q
515 2SD2395/EF/ TRANSISTOR
A
Q
516 DTA114YKA-X TRANSISTOR
Q
517 DTC114EKA-X TRANSISTOR
Q
518 KTC3203/OY/-T TRANSISTOR
A
Q
519 DTC114EKA-X TRANSISTOR
Q
520 2SD2395/EF/ TRANSISTOR
A
Q
522 DTA114EKA-X DIGITAL.TRANSIS
Q
523 DTC114EKA-X TRANSISTOR
Q
524 DTA114EKA-X DIGITAL.TRANSIS
Q
525 DTA114EKA-X DIGITAL.TRANSIS
Q
526 2SD2395/EF/ TRANSISTOR
A
Q
1501 DTC114TKA-X TRANSISTOR
Q
1502 DTC114TKA-X TRANSISTOR
Q
1503 DTC114TKA-X TRANSISTOR
Q
1504 KTC3199/GL/-T TRANSISTOR
Q
1505 KTC3199/GL/-T TRANSISTOR
Q
1506 KTC3199/GL/-T TRANSISTOR
Q
1511 KTC3199/GL/-T TRANSISTOR
Q
1512 KTC3199/GL/-T TRANSISTOR
Q
1513 KTC3199/GL/-T TRANSISTOR
Q
1514 DTC114EKA-X TRANSISTOR
Q
1520 DTC114EKA-X TRANSISTOR
Q
1523 2SC3576-JVC-T TRANSISTOR I/M
Q
1524 2SC3576-JVC-T TRANSISTOR I/M
Q
1525 2SC3576-JVC-T TRANSISTOR I/M
Q
1526 2SC3576-JVC-T TRANSISTOR I/M
Q
1527 KTA1267/YG/-T TRANSISTOR
Q
1528 KTA1267/YG/-T TRANSISTOR
Q
1531 DTA114YKA-X TRANSISTOR
Q
1532 DTA114YKA-X TRANSISTOR
R 501 NRSA63J-471X MG RESISTOR
R 502 NRSA63J-471X MG RESISTOR
R 503 NRSA63J-750X MG RESISTOR
R 504 NRSA63J-331X MG RESISTOR
R 505 NRSA63J-750X MG RESISTOR
R 506 NRSA63J-331X MG RESISTOR
R 507 NRSA63J-750X MG RESISTOR
R 508 NRSA63J-331X MG RESISTOR
R 509 NRSA63J-750X MG RESISTOR
R 510 NRSA63J-750X MG RESISTOR
R 511 NRSA63J-331X MG RESISTOR
R 513 NRSA63J-471X MG RESISTOR
R 514 NRSA63J-471X MG RESISTOR
R 515 NRSA63J-750X MG RESISTOR
R 516 NRSA63J-331X MG RESISTOR
R 517 NRSA63J-750X MG RESISTOR
R 518 NRSA63J-331X MG RESISTOR
R 519 NRSA63J-750X MG RESISTOR
R 520 NRSA63J-331X MG RESISTOR
R 521 NRSA63J-750X MG RESISTOR
R 522 NRSA63J-750X MG RESISTOR
R 523 NRSA63J-331X MG RESISTOR
R 525 NRSA63J-471X MG RESISTOR
R 526 NRSA63J-471X MG RESISTOR
R 527 NRSA63J-471X MG RESISTOR
R 528 NRSA63J-471X MG RESISTOR
R 529 NRSA63J-102X MG RESISTOR
R 530 NRSA63J-102X MG RESISTOR
R 531 NRSA63J-103X MG RESISTOR
R 532 NRSA63J-103X MG RESISTOR
R 533 NRSA63J-103X MG RESISTOR
R 534 NRSA63J-103X MG RESISTOR
R 535 NRSA63J-622X MG RESISTOR
R 536 NRSA63J-622X MG RESISTOR
R 537 NRSA63J-103X MG RESISTOR
R 538 NRSA63J-103X MG RESISTOR
R 541 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 542 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 545 NRSA63J-104X MG RESISTOR
R 546 NRSA63J-104X MG RESISTOR
R 547 NRSA63J-102X MG RESISTOR
R 548 NRSA63J-102X MG RESISTOR
R 549 NRSA63J-103X MG RESISTOR
R 550 NRSA63J-103X MG RESISTOR
R 552 NRSA63J-104X MG RESISTOR
R 554 NRSA63J-273X MG RESISTOR
R 556 NRSA63J-102X MG RESISTOR
R 557 NRSA63J-104X MG RESISTOR
R 558 NRSA63J-104X MG RESISTOR
R 559 NRSA63J-102X MG RESISTOR
Electrical parts list (Audio signal input board)
Block No. 03
Item
Parts number Parts name Ar
e
a
Remarks
A
