3-14

RX-E112RSL/RX-E111RSL

Item

Parts number Parts name Ar

Remarks

C 601 NCB31HK-102X C CAPACITOR

C 602 NCB31HK-102X C CAPACITOR

C 603 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 604 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 605 NCF31CZ-104X C CAPACITOR

C 606 NCF31CZ-104X C CAPACITOR

C 607 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 608 NCF31CZ-104X C CAPACITOR

C 609 NCF31CZ-104X C CAPACITOR

C 610 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 611 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 612 NCB31CK-103X C CAPACITOR

C 621 QEKC1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 622 NCS31HJ-101X C.CAPA. C.M

C 623 NCS31HJ-101X C.CAPA. C.M

C 624 NCF31CZ-104X C CAPACITOR

C 626 NCF31AZ-105X C CAPACITOR

C 627 NCF31AZ-105X C CAPACITOR

C 628 NCB31CK-103X C CAPACITOR

C 631 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 632 NCB31CK-103X C CAPACITOR

C 633 NCF31CZ-104X C CAPACITOR

C 634 NCF31CZ-104X C CAPACITOR

C 635 NCF31CZ-104X C CAPACITOR

C 636 NCB31CK-473X C CAPACITOR

C 638 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 639 NCB31CK-103X C CAPACITOR

C 640 NCB31CK-103X C CAPACITOR

C 641 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 642 NCB31CK-103X C CAPACITOR

C 643 NCB31AK-474X C CAPACITOR

C 644 NCB31CK-103X C CAPACITOR

C 645 NCS31HJ-101X C.CAPA. C.M

C 646 NCB31CK-103X C CAPACITOR

C 647 NCS31HJ-220X C CAPACITOR

C 648 NCS31HJ-180X C CAPACITOR

C 649 NCS31HJ-121X C CAPACITOR

C 653 NCB31CK-104X C CAPACITOR

C 654 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 661 NCB31CK-103X C CAPACITOR

C 671 NCB31CK-103X C CAPACITOR

C 672 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 673 NCB31CK-103X C CAPACITOR

C 677 NCS31HJ-101X C.CAPA. C.M

C 679 NCS31HJ-101X C.CAPA. C.M

C 681 NCB31CK-103X C CAPACITOR

C 682 NCB31CK-103X C CAPACITOR

C 683 NCB31CK-103X C CAPACITOR

C 684 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 685 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V

C 686 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V

C 687 NCB31CK-103X C CAPACITOR

C 688 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 689 NCB31CK-103X C CAPACITOR

C 690 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 691 NCB31HK-103X C CAPACITOR

C 693 NCB31CK-103X C CAPACITOR

C 694 NCF31CZ-104X C CAPACITOR

CN681 QGB2510K1-20 B TO B CONNE

C2500 QEKC1CM-226Z E CAPACITOR 22MF 20% 16V

C2503 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C2504 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C2507 NCS31HJ-330X C CAPACITOR

C2508 NCS31HJ-330X C CAPACITOR

C2512 NCF31CZ-104X C CAPACITOR

C2513 NCB31HK-122X C CAPACITOR

C2514 NCB31HK-122X C CAPACITOR

C2515 NCS31HJ-121X C CAPACITOR

C2516 NCS31HJ-121X C CAPACITOR

C2525 NCB31HK-102X C CAPACITOR

C2526 NCB31HK-102X C CAPACITOR

C2527 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C2528 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C2531 NCS31HJ-560X C CAPACITOR

C2532 NCS31HJ-560X C CAPACITOR

C2533 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C2534 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C2539 NCF31CZ-104X C CAPACITOR

C2540 NCF31CZ-104X C CAPACITOR

C2551 NCS31HJ-560X C CAPACITOR

C2552 NCS31HJ-560X C CAPACITOR

C2555 NCF31CZ-104X C CAPACITOR

C2556 NCF31CZ-104X C CAPACITOR

C2561 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V

C2562 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V

C2563 NCS31HJ-560X C CAPACITOR

C2564 NCS31HJ-560X C CAPACITOR

C2565 NCB31HK-102X C CAPACITOR

C2566 NCB31HK-102X C CAPACITOR

C2569 NCF31CZ-104X C CAPACITOR

C2570 NCF31CZ-104X C CAPACITOR

C2575 NCB31HK-102X C CAPACITOR

C2576 NCB31HK-102X C CAPACITOR

C2577 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C2578 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C2581 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V

C2582 QETN1CM-106Z E CAPACITOR 10MF 20% 16V

C2583 NCS31HJ-560X C CAPACITOR

C2584 NCS31HJ-560X C CAPACITOR

C2585 NCF31CZ-104X C CAPACITOR

C2586 NCF31CZ-104X C CAPACITOR

C2587 NCS31HJ-560X C CAPACITOR

C2588 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C2589 NCF31CZ-104X C CAPACITOR

C2590 NCF31CZ-104X C CAPACITOR

C2591 NCB31HK-102X C CAPACITOR

C2592 NCB31HK-103X C CAPACITOR

C2594 NCB31CK-473X C CAPACITOR

C2595 NCB31HK-102X C CAPACITOR

C2597 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C2598 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

D 607 1SS355-X DIODE C.M

D 608 1SS355-X DIODE C.M

D 609 1SS355-X DIODE C.M

D 610 1SS355-X DIODE C.M

IC601 AK4527BVQP IC

IC609 BA15218F-XE IC

IC610 BA15218F-XE IC

IC611 TC74HC08AF-X IC

IC612 TC74HC4072AF-X IC

IC621 TC74HCU04AF-W IC

IC631 TC9446F-025 IC

IC641 W24L010AJ-12-X IC

IC650 BA15218F-XE IC

IC651 BA15218F-XE IC

IC652 IMX9-W IC

Electrical parts list (DSP board)

Block No. 04

Item

Parts number Parts name Ar

Remarks
