3-15
RX-E112RSL/RX-E111RSL
Item
Parts number Parts name Ar
e
a
Remarks
A
IC661 BA15218F-XE IC
IC662 IMX9-W IC
IC671 UPD784215AGC167 IC(MICRO C ROM)
IC672 TC7SET32FU-X IC
IC681 BA033FP-X I.C.
IC682 IMX9-W IC
IC683 BA033LBSG-W IC
IC690 BA15218F-XE IC
IC691 BA15218F-XE IC
J 601 QNN0347-001 PIN JACK
K 601 NQR0269-004X FERRITE BEADS
Q
607 DTA144EKA-X TRANSISTOR
Q
670 DTC114YE-X TRANSISTOR
Q
671 2SD2114K/VW/-X CHIP TRANSISTOR
Q
672 DTC114YE-X TRANSISTOR
Q
673 DTA144EKA-X TRANSISTOR
Q
2501 DTA144EKA-X TRANSISTOR
R 600 NRSA63J-0R0X MG RESISTOR
R 601 NRSA63J-473X MG RESISTOR
R 602 NRSA63J-473X MG RESISTOR
R 603 NRSA63J-473X MG RESISTOR
R 606 NRSA63J-221X MG RESISTOR
R 607 NRSA63J-221X MG RESISTOR
R 608 NRSA63J-221X MG RESISTOR
R 609 NRSA63J-221X MG RESISTOR
R 611 NRSA63J-221X MG RESISTOR
R 612 NRSA63J-221X MG RESISTOR
R 613 NRSA63J-822X MG RESISTOR
R 615 NRSA63J-432X MG RESISTOR
R 617 NRSA63J-103X MG RESISTOR
R 618 NRSA63J-103X MG RESISTOR
R 620 NRSA63J-221X MG RESISTOR
R 621 NRSA63J-561X MG RESISTOR
R 622 NRSA63J-750X MG RESISTOR
R 623 NRSA63J-0R0X MG RESISTOR
R 627 NRSA63J-472X MG RESISTOR
R 628 NRSA63J-333X MG RESISTOR
R 631 NRSA63J-0R0X MG RESISTOR
R 632 NRSA63J-0R0X MG RESISTOR
R 639 NRSA63J-472X MG RESISTOR
R 640 NRSA63J-0R0X MG RESISTOR
R 641 NRSA63F-102X MG RESISTOR
R 642 NRSA63J-103X MG RESISTOR
R 643 NRSA63J-101X MG RESISTOR
R 644 NRSA63J-153X MG RESISTOR
R 645 NRSA63F-102X MG RESISTOR
R 646 NRSA63J-103X MG RESISTOR
R 647 NRSA63J-225X MG RESISTOR
R 648 NRSA63J-472X MG RESISTOR
R 657 NRSA63J-103X MG RESISTOR
R 661 NRSA63J-221X MG RESISTOR
R 662 NRSA63J-221X MG RESISTOR
R 663 NRSA63J-221X MG RESISTOR
R 664 NRSA63J-221X MG RESISTOR
R 668 NRSA63J-0R0X MG RESISTOR
R 669 NRSA63J-103X MG RESISTOR
R 670 NRSA63J-103X MG RESISTOR
R 671 NRSA63J-103X MG RESISTOR
R 672 NRSA63J-105X MG RESISTOR
R 673 NRSA63J-432X MG RESISTOR
R 674 NRSA63J-432X MG RESISTOR
R 675 NRSA63J-432X MG RESISTOR
R 676 NRSA63J-432X MG RESISTOR
R 677 NRSA63J-822X MG RESISTOR
R 678 NRSA63J-822X MG RESISTOR
R 679 NRSA63J-822X MG RESISTOR
R 680 NRSA63J-822X MG RESISTOR
R 682 NRSA63J-103X MG RESISTOR
R 683 NRSA63J-0R0X MG RESISTOR
R 684 NRSA63J-0R0X MG RESISTOR
R 687 NRSA63J-0R0X MG RESISTOR
R 688 NRSA63J-0R0X MG RESISTOR
R 689 NRSA63J-0R0X MG RESISTOR
R 691 NRSA63J-221X MG RESISTOR
R 692 NRSA63J-221X MG RESISTOR
R 693 NRSA63J-221X MG RESISTOR
R 694 NRSA63J-221X MG RESISTOR
R 695 NRSA63J-221X MG RESISTOR
R 696 NRSA63J-221X MG RESISTOR
R 697 NRSA63J-0R0X MG RESISTOR
R 698 NRSA63J-0R0X MG RESISTOR
R2500 NRSA63J-102X MG RESISTOR
R2501 NRSA63J-104X MG RESISTOR
R2502 NRSA63J-104X MG RESISTOR
R2507 NRSA63J-223X MG RESISTOR
R2508 NRSA63J-223X MG RESISTOR
R2509 NRSA63J-223X MG RESISTOR
R2510 NRSA63J-223X MG RESISTOR
R2511 NRSA63J-103X MG RESISTOR
R2512 NRSA63J-103X MG RESISTOR
R2513 NRSA63J-103X MG RESISTOR
R2514 NRSA63J-103X MG RESISTOR
R2515 NRSA63J-103X MG RESISTOR
R2516 NRSA63J-103X MG RESISTOR
R2519 NRSA63J-331X MG RESISTOR
R2520 NRSA63J-331X MG RESISTOR
R2521 NRSA63J-331X MG RESISTOR
R2522 NRSA63J-331X MG RESISTOR
R2525 NRSA63J-102X MG RESISTOR
R2526 NRSA63J-102X MG RESISTOR
R2527 NRSA63J-104X MG RESISTOR
R2528 NRSA63J-104X MG RESISTOR
R2529 NRSA63J-103X MG RESISTOR
R2530 NRSA63J-103X MG RESISTOR
R2531 NRSA63J-752X MG RESISTOR
R2532 NRSA63J-752X MG RESISTOR
R2533 NRSA63J-103X MG RESISTOR
R2534 NRSA63J-103X MG RESISTOR
R2535 NRSA63J-103X MG RESISTOR
R2536 NRSA63J-103X MG RESISTOR
R2537 NRSA63J-104X MG RESISTOR
R2538 NRSA63J-104X MG RESISTOR
R2550 NRSA63J-272X MG RESISTOR
R2551 NRSA63J-103X MG RESISTOR
R2552 NRSA63J-103X MG RESISTOR
R2553 NRSA63J-243X MG RESISTOR
R2554 NRSA63J-243X MG RESISTOR
R2555 NRSA63J-752X MG RESISTOR
R2556 NRSA63J-752X MG RESISTOR
R2557 NRSA63J-103X MG RESISTOR
R2558 NRSA63J-273X MG RESISTOR
R2560 NRSA63J-105X MG RESISTOR
R2561 NRSA63J-104X MG RESISTOR
R2562 NRSA63J-104X MG RESISTOR
R2563 NRSA63J-103X MG RESISTOR
R2564 NRSA63J-103X MG RESISTOR
Electrical parts list (DSP board)
Block No. 04
Item
Parts number Parts name Ar
e
a
Remarks
A
