MX-J200/J206
3-21
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 10
A
Item
Parts number Parts name Area
Remarks
A
R 612 NRSA02J-125X MG RESISTOR
R 631 NRSA02J-2R2X MG RESISTOR
R 632 NRSA02J-100X MG RESISTOR
R 634 NRSA02J-120X MG RESISTOR
R 635 NRSA02J-121X MG RESISTOR
R 636 NRSA02J-910X MG RESISTOR
R 651 NRSA02J-271X MG RESISTOR
R 652 NRSA02J-220X MG RESISTOR
R 657 NRSA02J-102X MG RESISTOR
R 658 NRSA02J-102X MG RESISTOR
R 661 NRSA02J-220X MG RESISTOR
R 662 NRSA02J-471X MG RESISTOR
R 663 NRSA02J-124X MG RESISTOR
R 665 NRSA02J-683X MG RESISTOR
R 666 NRSA02J-155X MG RESISTOR
R 667 NRSA02J-562X MG RESISTOR
R 671 NRSA02J-102X MG RESISTOR
R 672 NRSA02J-102X MG RESISTOR
R 673 NRSA02J-102X MG RESISTOR
R 674 NRSA02J-101X MG RESISTOR
R 675 NRSA02J-102X MG RESISTOR
R 676 NRSA02J-102X MG RESISTOR
R 677 NRSA02J-102X MG RESISTOR
R 678 NRSA02J-102X MG RESISTOR
R 679 NRSA02J-102X MG RESISTOR
R 680 NRSA02J-102X MG RESISTOR
R 681 NRSA02J-102X MG RESISTOR
R 682 NRSA02J-102X MG RESISTOR
R 683 NRSA02J-102X MG RESISTOR
R 684 NRSA02J-271X MG RESISTOR
R 685 NRSA02J-102X MG RESISTOR
R 686 NRSA02J-101X MG RESISTOR
R 687 NRSA02J-102X MG RESISTOR
R 688 NRSA02J-101X MG RESISTOR
R 689 NRSA02J-102X MG RESISTOR
R 690 NRSA02J-101X MG RESISTOR
R 691 NRSA02J-101X MG RESISTOR
R 692 NRSA02J-101X MG RESISTOR
R 693 NRSA02J-471X MG RESISTOR
R 694 NRSA02J-102X MG RESISTOR
R 801 NRSA02J-222X MG RESISTOR
R 802 NRSA02J-472X MG RESISTOR
R 803 NRSA02J-123X MG RESISTOR
R 804 NRSA02J-154X MG RESISTOR
R 805 NRSA02J-123X MG RESISTOR
R 806 NRSA02J-223X MG RESISTOR
R 807 NRSA02J-222X MG RESISTOR
R 808 NRSA02J-223X MG RESISTOR
R 811 NRSA02J-473X MG RESISTOR
R 812 NRSA02J-223X MG RESISTOR
R 831 NRSA02J-151X MG RESISTOR
R 832 NRSA02J-103X MG RESISTOR
R 842 NRSA02J-472X MG RESISTOR
R 851 NRSA02J-102X MG RESISTOR
R 852 NRSA02J-102X MG RESISTOR
R 853 NRSA02J-102X MG RESISTOR
R 854 NRSA02J-102X MG RESISTOR
R 855 NRSA02J-102X MG RESISTOR
R 856 NRSA02J-102X MG RESISTOR
R 857 NRSA02J-272X MG RESISTOR
R 859 NRSA02J-181X MG RESISTOR
R 861 NRSA02J-102X MG RESISTOR
R 862 NRSA02J-102X MG RESISTOR
R 863 NRSA02J-102X MG RESISTOR
R 864 NRSA02J-102X MG RESISTOR
R 865 NRSA02J-102X MG RESISTOR
R 866 NRSA02J-102X MG RESISTOR
R 880 NRSA02J-102X MG RESISTOR
R 881 NRSA02J-102X MG RESISTOR
R 882 NRSA02J-102X MG RESISTOR
R 883 NRSA02J-102X MG RESISTOR
R 884 NRSA02J-102X MG RESISTOR
R 885 NRSA02J-102X MG RESISTOR
R 886 NRSA02J-102X MG RESISTOR
R 887 NRSA02J-102X MG RESISTOR
W 601 QUB220-07HPDT SIN TWIST WIRE D.GND
X 251 QAX0360-001Z CRYSTAL FOR IC251
X 651 QAX0413-001Z CRYSTAL FOR IC651
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 11
A
CN804 QGB2016J1-07 CONNECTOR
SW 1 QSW0859-001 DETECT SWITCH
SW 2 QSW0859-001 DETECT SWITCH
SW 3 QSW0859-001 DETECT SWITCH
SW 4 QSW0859-001 DETECT SWITCH
SW 5 QSW0859-001 DETECT SWITCH
SW 6 QSW0859-001 DETECT SWITCH
(CD select switch board)
(CD servo board)
