For MX-K10 Fig.34 (A)
For MX-K10 Fig.34 (B)
X
YY
Clamp
AA
Prior to performing the following procedures,
remo
Also remove heat sink cover.(Fig. 4)
ve the top cover and both sides board.
1.
2.
3.
4.
5.
6.
7.
8.
Remove the two screws "A" connecting the heat
sink cover to the rear panel.(Fig. 2.3)
Pull out the heat sink co
3.
Remove teh three (MX-K10)/ four(MX-K30)screws
"AA" form the (MX-K10) chassis /MX-K30 back panel
between the heat sink.
ver toward you.
Remove the two screws "X" that retain the
speaker terminals and AUX terminal.
Remove the screw "YY" that retains the rear panel,
and then remove the rear panel.
Disconnect the parallel wires from the connectors
FW951 on the power trans PCB.
Remove the screw "Z" that retain the power amp
and supply PCB and then remove the assembly.
Remove the clamp of AC power cord from the
chassis.
Remove the four screws "AB" that retain the
power trans PCB and then remove the assembly.
Removing the power amp and supply
PCB and the power trans PCB
(See Fig.2, 3, 32, 34 to 37)
Fig.36
Rear panel
Chassis
Z
Power amp and
supply PCB
Clamp
Clamp
For MX-K30 Fig.34 (B)
For MX-K30 Fig.37 (B)For MX-K10 Fig.37 (A)
For MX-K10 Fig.35 (A) For MX-K30 Fig.35 (B)
FW951
FW951
x
Y
FUSE 952
1.6A 250V
FUSE 952
1.6A 250V
FUSE 951
1.6A 250V
FUSE 951
3.15A 250V
AB
AB
