JVC SP-UXJ55V User Manual

3-14
CD amp. board
Block No. [0][3][0][0]
R4306 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R4307 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R4502 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R4503 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R7309 QRE141J-161Y C RESISTOR 160 Ω 1/4W J
R7310 QRE141J-161Y C RESISTOR 160
Ω 1/4W J
R7311 QRE141J-161Y C RESISTOR 160
Ω 1/4W J
R7501 QRE141J-161Y C RESISTOR 160 Ω 1/4W J
R7510 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R7511 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R7512 QRE141J-122Y C RESISTOR 1.2k Ω 1/4W J
R7513 QRE141J-182Y C RESISTOR 1.8k Ω 1/4W J
R7514 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R7515 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R7516 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R7517 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R7520 QRE141J-182Y C RESISTOR 1.8k Ω 1/4W J
R7521 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R7522 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R7523 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R7524 QRE141J-333Y C RESISTOR 33k
Ω 1/4W J
R7600 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R7601 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R7602 QRE141J-122Y C RESISTOR 1.2k Ω 1/4W J
R7613 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R7615 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R7617 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
L4000 QQLZ035-R39 COIL 0.39uH
L4001 QQLZ035-R39 COIL 0.39uH
L5030 QQL231K-470Y COIL 47uH K
L5033 QQL231K-470Y COIL 47uH K
 T1001 QQT0370-011 POWER TRANSF
CN732 QGF1205F1-19 CONNECTOR FFC/FPC (1-19)
CN733 QGF1205F1-23 CONNECTOR FFC/FPC (1-23)
CN750 QGF1016F3-09 CONNECTOR FFC/FPC (1-9)
CN760 QGF1205F1-13 CONNECTOR FFC/FPC (1-13)
CN761 QGF1016F3-09 CONNECTOR FFC/FPC (1-9)
CN762 QGA2001F1-02 CONNECTOR W-B (1-2)
CN944 QGB2510K2-10 CONNECTOR B-B (1-10)
CN945 QGB2510K2-08 CONNECTOR B-B (1-8)
CN951 QGD2504C1-03Z CONNECTOR (1-3)
DI731 QLD0261-001 LCD MODULE
EP400 E409182-001SM GRAND TERMINAL
EP940 E409182-001SM GRAND TERMINAL
FW500 QUM154-15DGZ4 FLAT WIRE
FW945 QUM153-12DGZ4 FLAT WIRE
FW950 QUM156-16DGZ4 FLAT WIRE
 J1000 QGA7901C1-02 CONNECTOR W-B (1-2)
J5000 QNS0170-001 HEADPHONE JACK
JS751 QSW0993-001 ROTARY ENCODER
K5022 QQR0621-001Z COIL
 RY940 QSK0124-001 RELAY
 S1000 QSW0812-001 VOLTAGE SWITCH
S7510 QSW0825-001Z TACT SW
S7511 QSW0825-001Z TACT SW
S7512 QSW0825-001Z TACT SW
S7513 QSW0825-001Z TACT SW
S7514 QSW0825-001Z TACT SW
S7515 QSW0825-001Z TACT SW
S7516 QSW0825-001Z TACT SW
S7517 QSW0825-001Z TACT SW
S7520 QSW0825-001Z TACT SW
S7521 QSW0825-001Z TACT SW
S7522 QSW0825-001Z TACT SW
S7523 QSW0825-001Z TACT SW
S7601 QSW0825-001Z TACT SW
S7602 QSW0825-001Z TACT SW
S7603 QSW0825-001Z TACT SW
Z1000 QNG0003-001Z FUSE CLIP
Z1001 QNG0003-001Z FUSE CLIP
Z1002 QNG0003-001Z FUSE CLIP
Z1003 QNG0003-001Z FUSE CLIP
Z1004 QNG0003-001Z FUSE CLIP
Z1005 QNG0003-001Z FUSE CLIP
Z1006 QNG0003-001Z FUSE CLIP
Z1007 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
Z1008 QNG0003-001Z FUSE CLIP
Z1009 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
IC601 AN22000A-W IC
IC651 MN662748RPMFA IC
IC801 LA6541-X IC
IC802 LB1641 IC
IC851 MN101C30AEF IC
Q631 2SA1037AK/RS/-X TRANSISTOR
Q851 2SA952/LK/-T TRANSISTOR
D610 1SS133-T2 DIODE
D611 1SS133-T2 DIODE
D831 MTZJ5.6B-T2 Z DIODE
C600 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C601 NCB31HK-222X C CAPACITOR 2200pF 50V K
C602 NCB31HK-222X C CAPACITOR 2200pF 50V K
C603 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C604 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C605 NCS31HJ-471X C CAPACITOR 470pF 50V J
C606 NCS31HJ-820X C CAPACITOR 82pF 50V J
C610 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C612 EEKJ1HM-105ZJC E CAPACITOR 1uF 50V M
C613 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C614 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C615 NCB31HK-472X C CAPACITOR 4700pF 50V K
C616 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C617 NCS31HJ-331X C CAPACITOR 330pF 50V J
C619 NCS31HJ-330X C CAPACITOR 33pF 50V J
C621 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C622 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C623 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C624 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C631 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C632 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C633 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C641 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C642 NCB31HK-472X C CAPACITOR 4700pF 50V K
C643 NCB31HK-122X C CAPACITOR 1200pF 50V K
C651 NCS31HJ-120X C CAPACITOR 12pF 50V J
C652 NCS31HJ-120X C CAPACITOR 12pF 50V J
C655 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C656 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C657 QERF1AM-227Z E CAPACITOR 220uF 10V M
C659 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C661 NCS31HJ-471X C CAPACITOR 470pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C664 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C665 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C669 QERF1AM-227Z E CAPACITOR 220uF 10V M
C676 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C677 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C679 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C680 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C681 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C682 NCB31HK-102X C CAPACITOR 1000pF 50V K
C683 NCB31HK-102X C CAPACITOR 1000pF 50V K
C690 NCS31HJ-331X C CAPACITOR 330pF 50V J
C801 NCB31HK-682X C CAPACITOR 6800pF 50V K
C802 NCB31HK-472X C CAPACITOR 4700pF 50V K
C811 NCS31HJ-391X C CAPACITOR 390pF 50V J
C812 NCS31HJ-391X C CAPACITOR 390pF 50V J
C813 NCS31HJ-391X C CAPACITOR 390pF 50V J
C814 NCS31HJ-391X C CAPACITOR 390pF 50V J
C821 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C822 QERF1AM-227Z E CAPACITOR 220uF 10V M
C831 EEKJ1CM-107ZJC E CAPACITOR
 Symbol No. Part No. Part Name Description Local
