JVC TH-A55 Service Manual

1-2 (No.MB108)
SPECIFICATION
Designs & specifications are subject to change without notice.
Center unit
Audio Audio input sensitivity/Impedance (at 1 kHz), Total Harmonic Distortion 0.01 %
NOTE:
This value is measured at System cord CONNECTOR for reference.
Analog input AUDIO IN VCR 360 mV/47 kΩ
Digital input* DIGITAL IN (DBS) (OPTICAL) -21 dBm to -15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency - 32 kHz, 44.1 kHz, 48 kHz)
Video Color System NTSC/PAL selectable
Horizontal Resolution 500 lines
Signal-to-Noise Ratio 64 dB
Video output level Composite 1.0 V(p-p)/75 Ω
S-video-Y 1.0 V(p-p)/75 Ω
S-video-C 0.286 V(p-p)/75 Ω
Component-Y 1.0 V(p-p)/75 Ω
Component-PB/PR 0.7 V(p-p)/75 Ω
Video input sensitivity/
Impedance (VCR IN)
Composite 1.0 V(p-p)/75 Ω
S-video-Y 1.0 V(p-p)/75 Ω
S-video-C 0.286 V(p-p)/75 Ω
Tuner Tuning Range FM 87.50 MHz to 108.00 MHz
AM 531 kHz to 1 602 kHz (at 9 kHz intervals)
530 kHz to 1 600 kHz (at 10 kHz intervals)
General Power Requirements AC 240 V
·, 50 Hz
Power Consumption 20 W (at operation) 2.5 W (in standby mode)
Dimensions (W × H × D) 398 mm × 70 mm × 265 mm
Mass 2.7 kg
Subwoofer
Amplifier Front/Center/Surround 80 W per channel, RMS at 6 Ω at 1 kHz, with 10 % total harmonic distortion.
Subwoofer 120 W, RMS at 4 Ω at 100 Hz, with 10 % total harmonic distortion.
Speaker Speaker unit 20 cm Bass-reflex, Magnetically Shielded
Frequency Range 25 Hz to 200 Hz
General Power Requirements AC 240 V, 50 Hz
Power Consumption 150 W (at operation) 0 W (in standby mode)
Dimensions (W × H × D) 235 mm × 355 mm × 492 mm
Mass 13.0 kg
Front Speakers
Speakers 8 cm Bass-reflex, Magnetically Shielded
Power Handling Capacity 80 W
Impedance 6 Ω
Frequency Range 80 Hz to 20 kHz
Dimensions (W × H × D) 103 mm × 194 mm × 128 mm
Mass 0.77 kg
Center Speaker
Speakers 8 cm Bass-reflex, Magnetically Shielded
Power Handling Capacity 80 W
Impedance 6 Ω
Frequency Range 80 Hz to 20 kHz
Dimensions (W × H × D) 165 mm × 130 mm × 128 mm
Mass 0.77 kg
Surround Speakers
Speakers 8 cm Bass-reflex, Magnetically Shielded
Power Handling Capacity 80 W
Impedance 6 Ω
Frequency Range 80 Hz to 20 kHz
Dimensions (W × H × D) 103 mm × 194 mm × 128 mm
Mass 0.64 kg
