JVC TH-A5R Service Manual

TH-A5R
3-19
Item
Parts number Parts name
Are
a
Electrical parts list (Front board)
Remarks
Block No. 03
A
FW1 3708-000451 CONNECTOR
16P
,
1.25MM
,
ST
FW2 3711-000906 CONNECTOR
BOX
,
3P
,
2MM
,
AN
SW1 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW10 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW11 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW2 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW3 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW4 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW5 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW6 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW7 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW8 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
SW9 3404-001182 TACT SWITCH
DC12V
,
50MA
,
100G
UC1 2201-000783 C.CAPACITOR
100NF
,
+80%20%
,
5
UC2 2201-000783 C.CAPACITOR
100NF
,
+80%20%
,
5
UC3 2401-000475 E.CAPACITOR
10UF
,
20%
,
50V
UC4 2201-000565 C.CAPACITOR
47NF
,
+80% -20%
UC5 2201-000565 C.CAPACITOR
47NF
,
+80% -20%
UC6 2401-001912 E.CAPACITOR
1UF
,
20%
,
50V
UC7 2201-000783 C.CAPACITOR
100NF
,
+80%20%
,
5
UC80 2202-000797 C.CAPACITOR
10NF
,
30%
,
16V
,
Y5
UC9 2201-000389 C.CAPACITOR
22PF
,
5%
,
50V
,
NPO
UD1 0402-000127 DIODE
1N4002
,
100V
UD10 0402-000127 DIODE
1N4002
,
100V
UD2 0402-000127 DIODE
1N4002
,
100V
UD3 0401-000101 DIODE
1N4148
,
100V
UD4 0401-000101 DIODE
1N4148
,
100V
UEYE AC59-60060A REMOCON EYE
GP1U281R
,
38KHZ
UIC10 1003-001403 IC
LC75725E
,
QFP
,
64
ULD3 0601-001238 LED
RED
,
650NM
,
2.5MM
ULD4 0601-001432 LED
470NM
,
3MM
U
Q
1 0504-001003 TRANSISTOR
KSR2003TA
,
300MW
U
Q
2 0504-001003 TRANSISTOR
KSR2003TA
,
300MW
U
Q
3 0504-000118 TRANSISTOR
KSR1003
,
NPN
,
300
UR31 2001-000023 CARBON RESISTOR
47OHM
,
5%
,
1/4W
UR32 2001-000023 CARBON RESISTOR
47OHM
,
5%
,
1/4W
UR35 2001-000281 CARBON RESISTOR
100OHM
,
5%
,
1/8W
UR36 2001-000281 CARBON RESISTOR
100OHM
,
5%
,
1/8W
UR37 2001-000281 CARBON RESISTOR
100OHM
,
5%
,
1/8W
UR38 2001-000281 CARBON RESISTOR
100OHM
,
5%
,
1/8W
UR39 2001-000290 CARBON RESISTOR
10KOHM
,
5%
,
1/8W
UR40 2001-000734 CARBON RESISTOR
4.7KOHM
,
5%
,
1/8W
UR41 2001-000802 CARBON RESISTOR
5.6KOHM
,
5%
,
1/8W
UR42 2001-000062 CARBON RESISTOR
470OHM
,
5%
,
1/4W
UR43 2001-000554 CARBON RESISTOR
270OHM
,
5%
,
1/8W
UR44 2001-000660 CARBON RESISTOR
33KOHM
,
5%
,
1/8W
UR45 2001-000864 CARBON RESISTOR
56KOHM
,
5%
,
1/8W
UR69 2001-000429 CARBON RESISTOR
1KOHM
,
5%
,
1/8W
UR70 2001-000221 CARBON RESISTOR
1.2KOHM
,
5%
,
1/8W
UR71 2001-000241 CARBON RESISTOR
1.5KOHM
,
5%
,
1/8W
UR72 2001-000258 CARBON RESISTOR
1.8KOHM
,
5%
,
1/8W
UR73 2001-000472 CARBON RESISTOR
2.7KOHM
,
5%
,
1/8W
UR74 2001-000613 CARBON RESISTOR
3.9KOHM
,
5%
,
1/8W
UR75 2001-000802 CARBON RESISTOR
5.6KOHM
,
5%
,
1/8W
UR76 2001-000290 CARBON RESISTOR
10KOHM
,
5%
,
1/8W
UR77 2001-000411 CARBON RESISTOR
18KOHM
,
5%
,
1/8W
UR78 2001-000864 CARBON RESISTOR
56KOHM
,
5%
,
1/8W
UR80 2001-000290 CARBON RESISTOR
10KOHM
,
5%
,
1/8W
UZD1 0403-000369 ZENER DIODE
UZ8.2BM.500MW
VFD AH07-00056A VFD
HNV-11SS34T
