JVC TH-A5R Service Manual

TH-A5R
3-22
Item
Parts number Parts name Ar
e
a
Electrical parts list (DVD Loader board)
Remarks
Block No. 05
A
Item
Parts number Parts name Ar
e
a
Remarks
A
R118 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%1608
R119 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%1608
R12 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R120 2007-000082 CHI RESISTOR
3.3KOHM
,
5%
,
1608
R121 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1608
R122 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R123 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1608
R124 2007-000070 CHI RESISTOR
0OHM
,
5%
,
1608
R125 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R126 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1608
R127 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R128 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1608
R129 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R13 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R131 2007-000070 CHI RESISTOR
0OHM
,
5%
,
1608
R132 2007-001179 CHIP RESISTOR
8.2KOHM
,
5%
,
1608
R135 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%1608
R137 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%1608
R14 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R142 2007-000070 CHI RESISTOR
0OHM
,
5%
,
1608
R143 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R145 2007-000082 CHI RESISTOR
3.3KOHM
,
5%
,
1608
R147 2007-000082 CHI RESISTOR
3.3KOHM
,
5%
,
1608
R148 2007-000070 CHI RESISTOR
0OHM
,
5%
,
1608
R149 2007-000109 CHIP RESISTOR
1MOHM
,
5%
,
1608
R15 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R150 2007-000309 CHIP RESISTOR
10OHM
,
5%
,
1608
R151 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R152 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R153 2007-000078 CHI RESISTOR
1KOHM
,
5%
,
1608
R155 2007-002425 CHIP RESISTOR
1OHM
,
5%
,
1608
R156 2007-002425 CHIP RESISTOR
1OHM
,
5%
,
1608
R157 2007-002425 CHIP RESISTOR
1OHM
,
5%
,
1608
R158 2007-002425 CHIP RESISTOR
1OHM
,
5%
,
1608
R159 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1608
R16 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R160 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1608
R161 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1608
R162 2007-000077 CHI RESISTOR
470OHM
,
5%1608
R166 2007-000075 CHI RESISTOR
220OHM
,
5%
,
1608
R167 2007-000309 CHIP RESISTOR
10OHM
,
5%
,
1608
R168 2007-000078 CHI RESISTOR
1KOHM
,
5%
,
1608
R17 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1608
R170 2007-000078 CHI RESISTOR
1KOHM
,
5%
,
1608
R171 2007-000078 CHI RESISTOR
1KOHM
,
5%
,
1608
R173 2007-000070 CHI RESISTOR
0OHM
,
5%
,
1608
R18 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1608
R19 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%1608
R20 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1608
R22 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1608
R23 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R24 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R25 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R26 2007-000082 CHI RESISTOR
3.3KOHM
,
5%
,
1608
R27 2007-000082 CHI RESISTOR
3.3KOHM
,
5%
,
1608
R28 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R29 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R3 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1608
R30 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1608
R31 2007-000070 CHI RESISTOR
0OHM
,
5%
,
1608
R32 2007-000082 CHI RESISTOR
3.3KOHM
,
5%
,
1608
R33 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%1608
R34 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R35 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R36 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R38 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R39 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R4 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%1608
R45 2007-000078 CHI RESISTOR
1KOHM
,
5%
,
1608
R46 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R47 2007-000078 CHI RESISTOR
1KOHM
,
5%
,
1608
R48 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R49 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1608
R5 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R50 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%1608
R52 2007-000109 CHIP RESISTOR
1MOHM
,
5%
,
1608
R53 2007-000070 CHI RESISTOR
0OHM
,
5%
,
1608
R54 2007-000070 CHI RESISTOR
0OHM
,
5%
,
1608
R56 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R57 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R58 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R59 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R6 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1608
R60 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R61 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R62 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R63 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R64 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R65 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R66 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R67 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R68 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R69 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R7 2007-000078 CHI RESISTOR
1KOHM
,
5%
,
1608
R70 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R71 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R72 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R73 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R74 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R75 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R76 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R77 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R78 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R79 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R80 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1608
R82 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R83 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R84 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R85 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R86 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R87 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R88 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R89 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R90 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R91 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R92 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R93 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R94 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R95 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R96 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R97 2007-000074 CHI RESISTOR
100OHM
,
5%
,
1608
R98 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
R99 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1608
U1 1105-001372 IC
MHB416256A-35J
U10 1003-001418 IC
FAN8082
,
DIP
,
8P
U2 1204-001871 IC
M5701
,
PQFP
,
208P
