JVC TH-C60J

3-15
Audio board
Block No. [0][2]
R4834 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R4835 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4841 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R4843 QRT017J-2R2 MF RESISTOR 2.2 Ω 1W J
 R4844 QRZ9005-470X FUSI RESISTOR 47 Ω
R4846 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4848 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4849 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4852 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4861 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4863 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4864 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4866 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R4871 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4872 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4873 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4875 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4876 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4881 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4882 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4883 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R4884 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R4886 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R4891 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R4892 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R4893 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
 R4921 QRZ9005-100X FUSI RESISTOR 10 Ω
R4961 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
 L901 QQR0908-001 LINE FILTER
L951 QQL244K-R22Z COIL 0.22uH K
L955 QQL31AK-220Z COIL 22uH K
L957 QQL26AK-100Z COIL 10uH K
L972 QQL31AK-220Z COIL 22uH K
L4391 QQL25CK-221Z COIL 220uH K
 T901 QQS0371-001 SW TRANSF
CN401 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN402 QGF1036C2-28 CONNECTOR FFC/FPC (1-28)
CN403 QGF1036C2-18 CONNECTOR FFC/FPC (1-18)
CN404 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN410 QGF1205C2-11 CONNECTOR FFC/FPC (1-11)
CN411 QGF1036C2-25 CONNECTOR FFC/FPC (1-25)
CN413 QGB2501J1-06 CONNECTOR B-B (1-6)
CN450 QGF1036C2-17 CONNECTOR FFC/FPC (1-17)
CN451 QGF1205C2-07 CONNECTOR FFC/FPC (1-7)
CN457 QGD2504C1-03Z CONNECTOR (1-3)
 CP951 ICP-N10-T IC PROTECTOR 400mA
 CP999 ICP-N20-T IC PROTECTOR 800mA
EP401 QNZ0870-001 EARTH PLATE
EP901 QNZ0870-001 EARTH PLATE
EP903 QNZ0870-001 EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
FW521 QUM213-08DGZ4-E PARA RIBON WIRE
HS901 LV40057-002A HEAT SINK
J4401 QNN0570-001 PIN JACK
J4402 QNN0572-001 PIN JACK
J4891 QNS0089-001 3.5 JACK
J4891 or QNS0221-001 3.5 JACK
K4702 QQR0621-001Z COIL
 P901 QNC0082-001 AC INLET
PP401 QZW0112-001 WIRE CLAMP
PP402 QZW0112-001 WIRE CLAMP
PP403 QZW0112-001 WIRE CLAMP
PP404 QZW0112-001 WIRE CLAMP
S522 QSW1120-001Z PUSH SW I.M
S523 QSW1120-001Z PUSH SW I.M
S526 QSW1120-001Z PUSH SW I.M
S527 QSW1120-001Z PUSH SW I.M
S528 QSW1120-001Z PUSH SW I.M
S529 QSW1120-001Z PUSH SW I.M
X4701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC101 R2S15902FP IC
IC111 RC4580ID-X IC
IC112 RC4580ID-X IC
IC113 RC4580ID-X IC
IC121 RC4580ID-X IC
IC131 RC4580ID-X IC
IC501 PT6315 IC
IC511 GP1UM261XKVF IR DETECT UNIT
Q1101 2SA1530A/QR/-X TRANSISTOR
Q1102 RT1N141C-X DIGI TRANSISTOR
Q1121 IMX9-W TRANSISTOR
Q1122 IMX9-W TRANSISTOR
Q1123 IMX9-W TRANSISTOR
Q1131 RT1N141C-X DIGI TRANSISTOR
Q1132 2SA1530A/QR/-X TRANSISTOR
Q1133 IMX9-W TRANSISTOR
Q2921 KTC3203/OY/-T TRANSISTOR
D511 SLR-343VC/NPQ-T LED
D551 SELU2E10C-P LED
D2921 MTZJ11C-T2 Z DIODE
D2922 1SS133-T2 SI DIODE
C506 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB21CK-105X C CAPACITOR 1uF 16V K
C515 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C517 NCB31HK-102X C CAPACITOR 1000pF 50V K
C518 NCB31HK-102X C CAPACITOR 1000pF 50V K
C541 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C542 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NDC31HJ-331X C CAPACITOR 330pF 50V J
C1102 NDC31HJ-331X C CAPACITOR 330pF 50V J
C1103 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1104 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1111 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
C1112 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
C1170 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C60J,C60C,
C50J,C50C
C1170 NCB31HK-103X C CAPACITOR 0.01uF 50V K C40J,C40C
C1171 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C60J,C60C,
C50J,C50C
C1171 NCB31HK-103X C CAPACITOR 0.01uF 50V K C40J,C40C
C1172 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C60J,C60C,
C50J,C50C
C1172 NCB31HK-103X C CAPACITOR 0.01uF 50V K C40J,C40C
C1203 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1204 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1205 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1206 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1209 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1210 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1211 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1212 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1215 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1216 QTE1H46-475Z E CAPACITOR 4.7uF 50V
C60J,C60C,
C50J,C50C
C1216 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C40J,C40C
C1217 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1218 QTE1H46-475Z E CAPACITOR 4.7uF 50V
C60J,C60C,
C50J,C50C
C1218 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C40J,C40C
C1221 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1222 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1223 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1224 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1225 NDC31HJ-471X C CAPACITOR 470pF 50V J
C1226 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1441 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1442 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1443 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C1443 or QDXB1CM-222Y C CAPACITOR 2200pF 16V M
C1444 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C1444 or QDXB1CM-222Y C CAPACITOR 2200pF 16V M
