JVC TH-C60J

3-17
Mother board
Block No. [0][3]
R2511 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2512 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2513 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R2514 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R2520 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2521 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R2551 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R2552 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R2553 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R2554 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2555 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2556 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2557 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R2558 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2559 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2560 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2561 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2601 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2602 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2603 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2604 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2605 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R2606 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2607 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2608 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2609 QRE141J-390Y C RESISTOR 39 Ω 1/4W J
R2610 QRE141J-390Y C RESISTOR 39 Ω 1/4W J
R2611 QRE141J-100Y C RESISTOR 10 Ω 1/4W J
R2612 QRE141J-100Y C RESISTOR 10 Ω 1/4W J
R2613 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R2614 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R2620 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2621 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R2922 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6001 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6107 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
R6207 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
CN101 QGB2501J1-06 CONNECTOR B-B (1-6)
CN102 QGF1036F2-25 CONNECTOR FFC/FPC (1-25)
CN414 QGB2501K2-06 CONNECTOR B-B (1-6)
CN415 QGB2501K2-06 CONNECTOR B-B (1-6)
CN501 QGF1036F2-17 CONNECTOR FFC/FPC (1-17)
CN502 QGF1205F2-07 CONNECTOR FFC/FPC (1-7)
CN511 WJP0079-002A-E E-SH C WIRE C-B
DI501 QLF0168-001 FL TUBE
EP511 QNZ0870-001 EARTH PLATE
J1101 QNN0598-001 PIN JACK
J1103 QND0118-001 DIN CONNECTOR
J6001 QNS0231-001 JACK
J6101 QNZ0851-001 USB CONNECTOR
JS541 QSW1059-001 JOG VOLUME
K501 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K502 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K503 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K504 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K6001 NQR0007-002X FERRITE BEADS
K6002 NQR0007-002X FERRITE BEADS
K6003 NQR0007-002X FERRITE BEADS
K6004 NQR0007-002X FERRITE BEADS
K6101 NQR0502-001X FERRITE BEADS
K6102 NQR0022-002X FERRITE BEADS
K6103 NQR0022-002X FERRITE BEADS
K6104 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
S521 QSW1120-001Z PUSH SW I.M
S531 QSW0522-002Z PUSH SW I.M
S532 QSW0522-002Z PUSH SW I.M
S533 QSW0522-002Z PUSH SW I.M
S534 QSW0522-002Z PUSH SW I.M
S535 QSW0522-002Z PUSH SW I.M
S536 QSW0522-002Z PUSH SW I.M
S537 QSW0522-002Z PUSH SW I.M
S538 QSW0522-002Z PUSH SW I.M
S539 QSW0522-002Z PUSH SW I.M
S540 QSW0522-002Z PUSH SW I.M
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
 IC201 STK413-430 IC
 IC202 STK413-430 IC
IC301 RC4558D-X IC
IC302 RC4558D-X IC
IC303 RC4558D-X IC
IC601 MN101C427NB IC
Q152 KTC2026/Y/ TRANSISTOR
Q501 RT1P441C-X DIGI TRANSISTOR
Q502 2SC3928A/QR/-X TRANSISTOR
C60J,C60C,
C40J
Q502 KTC3875/YG/-X TRANSISTOR
C50J,C50C,
C40C
Q503 2SC3928A/QR/-X TRANSISTOR
C60J,C60C,
C40J
Q503 KTC3875/YG/-X TRANSISTOR
C50J,C50C,
C40C
Q504 2SA1530A/QR/-X TRANSISTOR
Q505 RT1N44HC-X DIGI TRANSISTOR
Q517 RT1N431C-X TRANSISTOR
Q523 2SC3928A/QR/-X TRANSISTOR
C60J,C60C,
C40J
Q523 KTC3875/YG/-X TRANSISTOR
C50J,C50C,
C40C
Q524 2SA1530A/QR/-X TRANSISTOR
Q525 2SC3928A/QR/-X TRANSISTOR
C60J,C60C,
C40J
Q525 KTC3875/YG/-X TRANSISTOR
C50J,C50C,
C40C
Q542 RT1N136C-X DIGI TRANSISTOR
Q603 2SC3928A/QR/-X TRANSISTOR
C60J,C60C,
C40J
Q603 KTC3875/YG/-X TRANSISTOR
C50J,C50C,
C40C
Q604 KTC3265/Y/-X TRANSISTOR
Q2101 2SA1530A/QR/-X TRANSISTOR
Q2201 2SA1530A/QR/-X TRANSISTOR
Q2301 2SA1530A/QR/-X TRANSISTOR
Q2401 2SA1530A/QR/-X TRANSISTOR
Q2501 2SA1530A/QR/-X TRANSISTOR
Q2601 2SA1530A/QR/-X TRANSISTOR
Q2701 2SC3928A/QR/-X TRANSISTOR
C60J,C60C,
C40J
Q2701 KTC3875/YG/-X TRANSISTOR
C50J,C50C,
C40C
Q2702 KTA1046/Y/ TRANSISTOR
Q2703 RT1N141C-X DIGI TRANSISTOR
Q2707 KTA1267/YG/-T TRANSISTOR
Q2708 KTC3199/GL/-T TRANSISTOR
Q2709 KTC2026/Y/ TRANSISTOR
C60J,C60C,
C50J,C50C
Q2710 2SA1530A/QR/-X TRANSISTOR
C60J,C60C,
C50J,C50C
Q2711 RT1P141C-X DIGI TRANSISTOR
C60J,C60C,
C50J,C50C
Q3702 RT1P141C-X DIGI TRANSISTOR
Q3703 RT1N241C-X DIGI TRANSISTOR
Q3704 KTC2026/Y/ TRANSISTOR
D101 1SS133-T2 SI DIODE
 D151 GBU803 BRIDGE DIODE
 D152 GBU803 BRIDGE DIODE
D154 1SS133-T2 SI DIODE
D163 1SS133-T2 SI DIODE
D164 MTZJ6.2B-T2 Z DIODE
D165 MTZJ6.8C-T2 Z DIODE
D166 MTZJ6.8C-T2 Z DIODE
D501 1SS133-T2 SI DIODE
D504 1SS133-T2 SI DIODE
D505 UDZS5.1B-X Z DIODE
D506 1SS133-T2 SI DIODE
D507 1SS355-X SI DIODE
D510 1SS133-T2 SI DIODE
D514 1SS133-T2 SI DIODE
D515 1SS133-T2 SI DIODE
D516 MTZJ30C-T2 Z DIODE
