JVC TH-C60J

3-20
DVD servo board
Block No. [0][4]
R2713 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R2721 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R2722 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R2723 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
C60J,C60C,
C50J,C50C
R2724 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
C60J,C60C,
C50J,C50C
R3101 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R3104 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R3105 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3106 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3107 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3109 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3110 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3111 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3201 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R3204 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3205 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3206 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3207 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R3209 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3210 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3211 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R3301 NRSA63J-203X MG RESISTOR 20k
Ω 1/16W J
R3304 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3305 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3306 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3307 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3309 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3310 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3311 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3401 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R3404 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3405 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3406 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3407 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3409 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3410 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3411 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3501 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R3504 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3505 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3506 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3507 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3509 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3510 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3511 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3601 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R3604 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R3605 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R3607 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R3610 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R3611 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3717 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3719 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
 R3720 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R3721 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
 R3727 QRL01DJ-180X OMF RESISTOR 18 Ω 1W J
R3732 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
L2101 QQLZ005-R45 COIL 0.45uH
L2201 QQLZ005-R45 COIL 0.45uH
L2301 QQLZ005-R45 COIL 0.45uH
L2401 QQLZ005-R45 COIL 0.45uH
L2501 QQLZ005-R45 COIL 0.45uH
L2601 QQLZ005-R45 COIL 0.45uH
 CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN102 QGA7901C1-02 CONNECTOR W-B (1-2)
CN151 QGA3901C1-05 CONNECTOR W-B (1-5)
CN271 QGB2510J1-14 CONNECTOR B-B (1-14)
CN272 QGB2510J1-09 CONNECTOR B-B (1-9)
CN273 QGB2510J1-14 CONNECTOR B-B (1-14)
CN274 QGA3901C1-02 CONNECTOR W-B (1-2)
CN371 QGA2501C1-02 CONNECTOR W-B (1-2)
CN372 QGB2510K2-09 CONNECTOR B-B (1-9)
CN501 QGB2510K2-14 CONNECTOR B-B (1-14)
CN502 QGB2510K2-14 CONNECTOR B-B (1-14)
 Symbol No. Part No. Part Name Description Local
EP201 QNZ0869-001 EARTH PLATE
EP501 QNZ0869-001 EARTH PLATE
FC102 QNG0019-001Z FUSE CLIP
FC156 QNG0019-001Z FUSE CLIP
FC158 QNG0019-001Z FUSE CLIP
FW501 QUM213-28Z4Z4-E RIBBON WIRE
HS151 QZW0115-001 HEAT SINK
C60J,C60C,
C50J,C50C
HS151 QZW0138-001 HEAT SINK C40J,C40C
J2701 QND0118-001 DIN CONNECTOR
J2702 QNB0195-001 SPEAKER TERMINA
 RY101 QSK0142-001 RELAY
RY271 QSK0127-001 RELAY
RY272 QSK0127-001 RELAY
RY273 QSK0127-001 RELAY
TH271 NAD0025-103X N THERMISTOR 10k Ω
WC201 QZW0112-001 WIRE CLAMP
X601 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 ES8381FCC IC
IC302 MM1701EH-X IC
IC305 MM1663DH-X IC
IC306 MM1565AF-X IC
IC309 TC74VHC574FT-X IC
IC451 MN101C61GNW IC
IC452 BR93L56RF-W-X IC
IC453 S-80830CNNB-G-W IC
IC505 K4S281632F-UC60 IC(DIGITAL)
IC509 --------------------- IC
IC510 BR24L16F-W-X IC
IC701 AK4387ET-X IC
IC702 AK4387ET-X IC
IC703 AK4387ET-X IC
IC704 AK5358ET-X IC
IC705 MM1615AN-X IC
IC801 SII9030CTU IC
IC802 SN74CB3T3306U-X IC
IC804 MM3141JN-X IC
IC805 MM3143DN-X IC
IC806 LD2981ABM50-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q801 2SA1530A/R/-X TRANSISTOR
Q802 2SC3928A/R/-X TRANSISTOR
Q803 2SC3928A/R/-X TRANSISTOR
D301 UDZW5.6B-X Z DIODE
D302 UDZW5.6B-X Z DIODE
D305 RB521S-30-X SB DIODE
D801 NAF0013-001X ESD SUPPRESSOR V
D802 NAF0013-001X ESD SUPPRESSOR V
D803 BAV99L-X SI DIODE
C101 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C102 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C103 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C104 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C105 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C106 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C107 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C108 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C109 NCB31HK-102X C CAPACITOR 1000pF 50V K
C110 NCB31HK-102X C CAPACITOR 1000pF 50V K
C111 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C201 NDC31HJ-221X C CAPACITOR 220pF 50V J
 Symbol No. Part No. Part Name Description Local
