JVC TH-C60J

3-23
DVD loading board
Block No. [0][5]
R833 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R834 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R837 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R838 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R839 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R840 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R841 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R842 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R843 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R844 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R890 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R891 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R899 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L311 NQL044K-220X COIL 22uH K
L801 NQR0597-001X EMI FILTER
L802 NQR0597-001X EMI FILTER
L803 NQR0597-001X EMI FILTER
L804 NQR0597-001X EMI FILTER
CN101 QGF0523F3-24W CONNECTOR FFC/FPC (1-24)
CN201 QGF1016F8-08W CONNECTOR FFC/FPC (1-8)
CN451 QGF1016F8-15W CONNECTOR FFC/FPC (1-15)
CN452 QGA2001F6-02X CONNECTOR W-B (1-2)
CN453 QGA2001F6-03X CONNECTOR W-B (1-3)
CN701 QGF1016C6-28W CONNECTOR FFC/FPC (1-28)
CN702 QGF1016C6-18W CONNECTOR FFC/FPC (1-18)
CN703 QGF1016C6-05W CONNECTOR FFC/FPC (1-5)
CN704 QGA2001F6-05X CONNECTOR W-B (1-5)
CN801 QGF1016C6-05W CONNECTOR FFC/FPC (1-5)
J801 NNZ0161-001 CONNECTOR
K101 NQR0502-001X FERRITE BEADS
K125 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K301 NQR0502-001X FERRITE BEADS
K302 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K303 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K304 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K305 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K306 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K307 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K308 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K309 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K310 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K317 NQR0022-002X FERRITE BEADS
K318 NQR0022-002X FERRITE BEADS
K373 NQR0360-002X FERRITE BEADS
K374 NQR0360-002X FERRITE BEADS
K375 NQR0360-002X FERRITE BEADS
K376 NQR0360-002X FERRITE BEADS
K378 NQR0360-002X FERRITE BEADS
K379 NQR0360-002X FERRITE BEADS
K380 NQR0360-002X FERRITE BEADS
K381 NQR0360-002X FERRITE BEADS
K384 NQR0360-002X FERRITE BEADS
K385 NQR0360-002X FERRITE BEADS
K386 NQR0360-002X FERRITE BEADS
K387 NQR0360-002X FERRITE BEADS
K388 NQR0360-002X FERRITE BEADS
K454 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K455 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K456 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K501 NQR0502-001X FERRITE BEADS
K701 NQR0022-005X FERRITE BEADS
K702 NQR0022-005X FERRITE BEADS
K703 NQR0022-005X FERRITE BEADS
K704 NQR0022-005X FERRITE BEADS
K705 NQR0022-005X FERRITE BEADS
K706 NQR0022-005X FERRITE BEADS
K707 NQR0022-002X FERRITE BEADS
K708 NQR0022-002X FERRITE BEADS
K709 NQR0022-002X FERRITE BEADS
K710 NQR0022-002X FERRITE BEADS
K711 NQR0022-002X FERRITE BEADS
K712 NQR0022-005X FERRITE BEADS
K713 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K714 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K721 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K722 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
K801 NQR0502-001X FERRITE BEADS
K802 NQR0502-001X FERRITE BEADS
K803 NQR0502-001X FERRITE BEADS
K804 NQR0502-001X FERRITE BEADS
K805 NQR0502-001X FERRITE BEADS
K812 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K813 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
RN551 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RN552 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RN553 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
RN554 NRZ0034-330W NET RESISTOR 33 Ω 1/32W J x4
X301 NAX0741-001X CRYSTAL
X451 NAX0248-001X C OSCILLATOR
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
CN1 QGF1036F2-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-002 PUSH SWITCH
SW2 QSW0844-002 PUSH SWITCH
SW3 QSW0844-002 PUSH SWITCH
SW4 QSW0844-002 PUSH SWITCH
SW5 QSW0844-002 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW7 QSW0886-002 DETECT SWITCH
SW8 QSW0923-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
