JVC TH-C9 User Manual

SCHEMATIC DIAGRAMS
No.MB427SCH
2005/8
TH-C9
Contents
Block diagram
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-13 to 17
DVD DIGITAL CINEMA SYSTEM
CD-ROM No.SML200508
COPYRIGHT 2005 Victor Company of Japan, Limited.
Area suffix
US ------------------------ Singapore
UT ---------------------------- Taiwan
UX -------------------- Saudi Arabia
UG --- Turkey,South Africa,Egypt
UN ----------------------------- Asean
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
(XV-THC9)
(SP-PWC9)
(SP-THC9C)(SP-THC9F) (SP-THC9F)
(SP-THC9S)
