JVC TH-C9 - Page 89

3-25
Loading board
Block No. [0][7]
K734 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K735 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K736 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K737 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K738 NQR0022-005X FERRITE BEADS
K741 NQR0022-002X FERRITE BEADS
K744 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K748 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K749 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K750 NQR0022-002X FERRITE BEADS
K752 NQR0022-002X FERRITE BEADS
K754 NQR0022-002X FERRITE BEADS
K756 NQR0022-002X FERRITE BEADS
K758 NQR0022-002X FERRITE BEADS
TH301 NAD0025-103X N THERMISTOR 10k Ω
X301 NAX0741-001X CRYSTAL
X451 NAX0248-001X C OSCILLATOR 8.000MHz
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW8 QSW0923-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
