JVC TH-D337H Quick Start Guide

•
Connecting to the Mains Supply
Soundbar
Unwind the mains cable to its full length. Connect the end of the cable to the AC ~ Socket at the rear of the unit and then connect the mains
plug to the mains socket. Make sure the mains plug is fully inserted into the mains socket.
The soundbar is designed to operate with the supplied mains cable.
• Connecting the unit to any other power source may damage the unit.
• Ensure all audio connections of the unit are connected before connecting to the mains power socket.
• Make sure the mains plug is rmly inserted into the mains socket.
• To switch the unit o completely, remove the mains plug from the mains socket.
• Please turn the unit o completely to save energy when not in use.
• The mains cable are designed for this JVC soundbar only. DO NOT use the mains cable for other purposes.
•
Connecting the Subwoofer to the Soundbar
Connect the subwoofer cable into the SUBWOOFER OUT sockect of the soundbar.
Still Need Help Connecting Your Soundbar?
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
CUSTOMER SERVICE - 1-800-289-0984
FOR RECYCLING INFORMATION, PLEASE CONTACT CUSTOMER SERVICE.
CUSTOMER SERVICE - 1-800-289-0984
Well done, your new soundbar is now ready to use. You will nd that there are many exciting features available. To get to know all
these features, please take some time to read the instruction manual provided with your soundbar.
(QSG-TH-D337H-GB-180620V3)
Connection
•
Ensure the colours on the cable plugs match with the colours on the input and output sockets.
Method 3: AUX Connection
Use a 3.5mm to RCA stereo audio cable (not included) or a 3.5mm to 3.5mm stereo audio cable (included) to connect the soundbar’s AUX 1/
AUX 2 socket to the AUDIO OUT /HEADPHONES sockets of the external device.
After connection, press button on the unit or remote control to switch the unit on.
Press SOURCE on the unit or AUX 1 / AUX 2 on the remote control repeatedly to select AUX 1 / AUX 2 to play audio from your input device.
Front View of the Subwoofer
Rear View of the Soundbar
To the
mains socket
Rear View of the Soundbar
Norway: www.elkjop.no/service Sweden: www.elgiganten.se/service
Denmark: www.elgiganten.dk/service Finland: www.gigantti./huolto
Rear View of the Soundbar
Blu-ray Player / DVD
Player / Recorder
Set-top Box
Satellite
Receiver
Game
Console
Video
Camera
MP3 Player or
Mobile Device
OR
3.5mm to 3.5mm Stereo Audio
Cable (included)
3.5mm to RCA Stereo Audio
Cable (not included)
TH-D337H_QSG_Final180620V3.indd 2 21/6/2018 1:57 PM

JVC TH-D337H Specifications

Power

power supply	AC120V~ 60Hz
power consumption	30 W
output power	30 W x 2

Connectivity

bluetooth version	V 4.2
maximum power transmitted	<20 dbm
frequency bands	2402 MHz ~ 2480 MHz

Audio Input

usb socket	5V == 0.5A
audio input sensitivity	700mV
frequency response	120Hz - 20KHz

Remote Control

distance	6m
angle	30°
battery type	CR2025

Weight and Dimensions

unit dimension	952 x 63 x 65.7 mm
